Brand new AS-PL Alternator
STANDARD LINE
AS-PL
HITACHI
Price:
NZ$ 1,269.04 including GST
NZ$ 1,103.51 excluding GST
or four payments of $317.26
with
Learn More
each
A2102S
1
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
LR1190-916Associated Numbers
059903015T 059903016T 059903016TX 136144 2020245 205.409.190 2506144 28-6890 4525 553525RIH 554276RIH AEK3780 ALH3096 ALH3096NW CAL20245 CAL20245AS CAL20245ES CAL20245GS CAL20245OS CAL20245RS EAA-224252 HITLR1190-916 LR1190-916 LR1190-940 LRA03780 LRA3780 UD13142A Volkswagen 2020237 Sando 205410190 PSH 20632N WAI 288703 Elstock 40832 CEVAM 441994 Logistik 554276RI DAS 89214414 Power Max A131529 Short code A158162 A161571 ALT32359 Wood Auto CAL20237 Airframe LR1190940 Hitachi LR1190940SEL +line WOOALT32359Specifications
| Amp | 190 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 9 mm |
| Diameter (D.2) | 9 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Length (L.1) | 209 mm |
| Mount Inside Length or Pad Mount C-C (C) | 61 mm |
| OEM Product | No |
| Plug Code | PL_2303 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 56 mm |
| Pulley to Mount Distance (A) | 30 mm |
| Pulley Type | Clutch |
| Unit Type | HITACHI |
| Voltage | 12 V |
| Water Cooled | Yes |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A8 2.8 FSi | [BDX] | 01.2007-12.2010 |
| AUDI | A8 2.8 FSi | [BDX] | 08.2007-07.2010 |
| AUDI | A8 3.2 FSi | [BPK] | 01.2005-12.2010 |
| AUDI | A8 3.2 FSi | [BPK] | 06.2005-07.2010 |
| AUDI | A8 3.2 FSi Quattro | [BPK] | 01.2005-12.2010 |
| AUDI | A8 3.2 FSi Quattro | [BPK] | 06.2005-07.2010 |
| AUDI | A8 4.2 TDi Quattro | [BMC] | 01.2005-06.2005 |
| AUDI | A8 4.2 TDi Quattro | [BMC] | 01.2005-12.2010 |
| AUDI | A8 4.2 TDi Quattro | [BVN] | 01.2005-12.2010 |
| AUDI | A8 4.2 TDi Quattro | [BVN] | 07.2005-07.2010 |
| AUDI | Q7 4.2 TDi | [BTR] | 01.2007-12.2009 |
| AUDI | Q7 4.2 TDi Quattro | [BTR] | 03.2007-06.2009 |
| AUDI | Q7 6.0 TDi | [CCGA] | 01.2008-12.2014 |
| VW | Phaeton 3.0 V6 TDi | [CEXA] | 01.2011- |
| VW | Phaeton 3.0 V6 TDi | [CEXB] | 01.2011- |
| VW | Phaeton 3.0 V6 TDi 4motion | [CARB] | 11.2008-03.2016 |
| VW | Phaeton 3.0 V6 TDi 4motion | [CEXA] | 11.2008-03.2016 |
| VW | Phaeton 3.0 V6 TDi 4motion | [CEXB] | 11.2013-03.2016 |
Reference Information
| 059903015T | VW |
| 114241 | FARCOM |
| 12090728 | EUROTEC |
| 136144 | HITACHI |
| 20020245AV | ITAB AUTOMOTIVE |
| 20145542BN | REAL |
| 20145542OE | REAL |
| 2020245.0 | SANDO |
| 2020245.1 | SANDO |
| 205.409.190.080 | PSH |
| 205.409.190.088 | PSH |
| 2115101902 | DRI |
| 2506144 | HITACHI |
| 28-6890 | ELSTOCK |
| 3114830 | HENKEL PARTS |
| 4525 | CEVAM |
| 553525RI | KUHNER |
| 89215853 | POWERMAX |
| A2102S | AS-PL |
| AEK3780 | AUTOELECTRO |
| AHI245 | AUTOTEAM |
| AHI245A | AUTOTEAM |
| AL03356 | TMI |
| ALH3096 | KRAUF |
| ALT222450 | SIOM |
| ALT3064 | ELECTROLOG |
| ALT32347 | WOODAUTO |
| CAL20245AS | CASCO |
| CAL20245GS | CASCO |
| HAL1190916 | HITACHI |
| LR1190-916 | HITACHI |
| LRA03780 | LUCAS |
| LRA3780 | LUCAS |
| UD13142A | AS-PL |
Video/Publications
