Brand new AS-PL Alternator
STANDARD LINE
AS-PL
HITACHI
Price:
NZ$ 435.92 including GST
NZ$ 379.06 excluding GST
or four payments of $108.98
with
Learn More
each
A2109S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Information
LR190-744Associated Numbers
LR190-744 UD20722A CAL20185AS A-8929 LR190761 2902768200 2902768300 8972043320 8973553400 ALH3367 554870RI 9214066 135.935.090 20145581BN 2020185.0 13825N 90-25-1137N 90-25-1137 ALT32143Specifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 56.50 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 10.50 mm |
| Length (L.1) | 183 mm |
| OEM Product | No |
| Plug Code | PL_2004 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 57 mm |
| Pulley to Mount Distance (A) | 90.50 mm |
| Pulley Type | Solid |
| Unit Type | HITACHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HONDA | Passport 3.2 | 01.1999-12.1999 | |
| HONDA | Passport 3.2 | 01.2000-12.2000 | |
| HONDA | Passport 3.2 | 01.2001-12.2001 | |
| HONDA | Passport 3.2 | 01.2002-12.2002 | |
| ISUZU | Amigo 3.2 | 01.1998-12.1998 | |
| ISUZU | Amigo 3.2 | 01.2000-12.2000 | |
| ISUZU | Amigo 3.2 | 01.2002-12.2002 | |
| ISUZU | Rodeo 3.2 | 01.1999-12.1999 | |
| ISUZU | Rodeo 3.2 | 01.2000-12.2000 | |
| ISUZU | Rodeo 3.2 | 01.2001-12.2001 | |
| ISUZU | Rodeo 3.2 | 01.2002-12.2002 | |
| ISUZU | Rodeo 3.2 | 01.2003-12.2003 | |
| ISUZU | Rodeo 3.2 | 01.2004-12.2004 | |
| ISUZU | Rodeo 3.5 | 01.2004-12.2004 |
Reference Information
| 135.935.090 | PSH |
| 135.935.090.088 | PSH |
| 135.935.090.460 | PSH |
| 13825N | WAI / TRANSPO |
| 20145581BN | REAL |
| 2020185.0 | SANDO |
| 2902768200 | ISUZU |
| 2902768300 | ISUZU |
| 554870RI | KUHNER |
| 8972043320 | ISUZU |
| 8973553400 | ISUZU |
| 90-25-1137 | WILSON |
| 90-25-1137N | WILSON |
| 9214066 | POWERMAX |
| A-8929 | DIXIE |
| ALH3367 | KRAUF |
| ALT221850 | SIOM |
| ALT221850A | SIOM |
| ALT3205 | ELECTROLOG |
| ALT32143 | WOODAUTO |
| ALTE369 | 3EFFE |
| CAL20185AS | CASCO |
| LR190-744 | HITACHI |
| LR190761 | HITACHI |
| PRAE369 | 3EFFE |
| UD20722A | AS-PL |
Video/Publications
A2109SRelated Items
