Information
LR1100-709Associated Numbers
LR1100-709 UD20720A A-8712 LR1100709B LR1100709C ALH3373 231000Z400 231009E000 9214038 13760N 13760R 90-25-1124N 90-25-1124Specifications
Amp | 100 A |
Bottom Mounting Foot Width (B) | 25 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 11 mm |
Diameter (D.3) | 10.50 mm |
Length (L.1) | 172 mm |
Mount Inside Length or Pad Mount C-C (C) | 81 mm |
OEM Product | No |
Plug Code | PL_2004 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Grooves | 6 qty |
Pulley Outside Diameter (O.D.1) | 55 mm |
Pulley to Mount Distance (A) | 35.50 mm |
Pulley Type | Solid |
Unit Type | HITACHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
NISSAN | Altima 2.4 | 01.1998-12.1998 | |
NISSAN | Altima 2.4 | 01.1999-12.1999 | |
NISSAN | Altima 2.4 | 01.2000-12.2000 | |
NISSAN | Altima 2.4 | 01.2001-12.2001 |
Reference Information
13760N | WAI / TRANSPO |
13760R | WAI / TRANSPO |
231000Z400 | NISSAN |
231009E000 | NISSAN |
90-25-1124 | WILSON |
90-25-1124N | WILSON |
9214038 | POWERMAX |
A2110S | AS-PL |
A-8712 | DIXIE |
ALH3373 | KRAUF |
LR1100-709 | HITACHI |
LR1100709B | HITACHI |
LR1100709C | HITACHI |
UD20720A | AS-PL |
Video/Publications
A2110SRelated Items
