Brand new AS-PL Alternator
STANDARD LINE
AS-PL
VALEO
Price:
NZ$ 400.81 including GST
NZ$ 348.53 excluding GST
or four payments of $100.20
with
Learn More
each
A3025
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
A14N102Associated Numbers
11.0831 111324 2015190 2015205 20179091RC 20179502RC 28-1872 30831RI 32037311 35214350 35214420 436594 4902 56190 56250 7700730365 8111712 8EL731692-001 9213258 A14N102 A14N74 AEA5166 ALT14124 CA831IR CAL15190RS CAL15205RS DRA3079 LRA00566 NA315Specifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 27 mm |
| Diameter (D.1) | 8.50 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 10.50 mm |
| Length (L.1) | 172 mm |
| Mount Inside Length or Pad Mount C-C (C) | 63 mm |
| OEM Product | No |
| Plug Code | PL_2703 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 65 mm |
| Pulley to Mount Distance (A) | 47.50 mm |
| Pulley Type | Solid |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| RENAULT | 19 1.7 Chamade | 09.1988-08.1995 | |
| RENAULT | R19 1.7 | [F3N740] | 09.1988-12.1995 |
| RENAULT | R19 1.7 | [F3N741] | 09.1988-12.1995 |
| RENAULT | R19 1.7 | [F3N742] | 04.1992-06.1996 |
| RENAULT | R19 1.7 | [F3N743] | 04.1992-06.1996 |
| RENAULT | R19 1.8 | [F3P682] | 05.1992-12.1995 |
| RENAULT | R19 1.8 | [F3P700] | 04.1992-05.1994 |
| RENAULT | R19 1.8 | [F3P704] | 04.1992-06.1996 |
| RENAULT | R19 1.8 | [F3P705] | 04.1992-06.1996 |
| RENAULT | R19 1.8 | [F3P706] | 04.1992-06.1996 |
| RENAULT | R19 1.8 | [F3P707] | 04.1992-06.1996 |
| RENAULT | R19 1.8 | [F3P708] | 04.1992-06.1996 |
| RENAULT | R19 1.8 | [F3P760] | 04.1992-06.1996 |
| RENAULT | R19 1.8 | [F3P764] | 11.1994-06.1996 |
| RENAULT | R19 1.8 | [F3P765] | 10.1994-06.1996 |
| RENAULT | R19 1.8 RT | [F3P700] | 04.1992-05.1994 |
| RENAULT | R19 1.8 RT | [F3P706] | 04.1992-12.1995 |
| RENAULT | R19 1.8 RT | [F3P760] | 04.1992-12.1995 |
| RENAULT | R21 1.7 | [F2N710] | 03.1986-12.1995 |
| RENAULT | R21 1.7 | [F2N712] | 03.1986-03.1993 |
| RENAULT | R21 1.7 | [F2N750] | 03.1986-12.1994 |
| RENAULT | R21 1.7 | [F2N752] | 06.1987-04.1989 |
| RENAULT | R21 1.7 | [F3N722] | 03.1986-12.1995 |
| RENAULT | R21 1.7 | [F3N723] | 03.1986-12.1995 |
| RENAULT | R21 1.7 | [F3N726] | 03.1986-12.1995 |
Reference Information
| 11.0831 | LAUBER |
| 111324 | CARGO |
| 2015190 | SANDO |
| 2015205 | SANDO |
| 20179091RC | REAL |
| 20179502RC | REAL |
| 28-1872 | ELSTOCK |
| 30831RI | KUHNER |
| 32037311 | HERTH+BUSS |
| 35214350 | PRESTOLITE |
| 35214420 | PRESTOLITE |
| 436594 | VALEO |
| 440978 | LOGISTIK |
| 4902 | CEVAM |
| 542065 | RENAULT |
| 56190 | EAI |
| 56250 | EAI |
| 7700730365 | RENAULT |
| 7701352115 | RENAULT |
| 8111712 | VOLVO |
| 8EL731692-001 | HELLA |
| 9213258 | POWERMAX |
| A14N102 | VALEO |
| A14N74 | VALEO |
| AEA5166 | AUTOELECTRO |
| ALT00732 | ELECTROLOG |
| ALT14124 | WOODAUTO |
| ALT171900 | SIOM |
| ALT172050 | SIOM |
| ALT4520 | SIOM |
| ALTF507 | 3EFFE |
| ALTS065 | 3EFFE |
| ANM35299X | ANDEL |
| CA831IR | HC PARTS |
| CAL15190RS | CASCO |
| CAL15205RS | CASCO |
| DRA3079 | DELCO |
| F032111324 | CARGO |
| LRA00566 | LUCAS |
| LRA566 | LUCAS |
| NA315 | VALEO |
| STX101248 | STARDAX |
Video/Publications
