Brand new AS-PL Alternator
STANDARD LINE
AS-PL
VALEO
Price:
NZ$ 671.98 including GST
NZ$ 584.33 excluding GST
or four payments of $168.00
with
Learn More
each
AAM-C6157
A3209S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Associated Numbers
03G903016A 03G903016AX 114831 2015176 20444R 205.532.180 209423 2542827 2543374 28-5788 301910RI 301910RIV 437542 542827 57422 8EL012429-811 8EL738211-691 AEK3176 CA1910IR CAL15176 CAL15176AS CAL15176ES CAL15176GS CAL15176OS CAL15176RS EAA-222448 LRA03176 TG17C024 TG17C054 UD13410A VALTG17C054Specifications
| Amp | 180 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8 mm |
| Diameter (D.2) | 8 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Length (L.1) | 194 mm |
| Mount Inside Length or Pad Mount C-C (C) | 61.50 mm |
| OEM Product | No |
| Plug Code | PL_2303 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 56 mm |
| Pulley to Mount Distance (A) | 38.50 mm |
| Pulley Type | Clutch |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A6 2.0 TDi | [BLB] | 06.2005- |
| AUDI | A6 2.0 TDi | [BLB] | 07.2004- |
| AUDI | A6 2.0 TDi | [BNA] | 06.2005- |
| AUDI | A6 2.0 TDi | [BRE] | 06.2005- |
| AUDI | A6 2.0 TDi | [BRE] | 07.2004- |
| AUDI | A6 2.0 TDi | [BRF] | 06.2005- |
| AUDI | A6 2.0 TDi | [BVG] | 09.2005- |
| AUDI | A6 2.7 TDi | [BPP] | 01.2004- |
| AUDI | A6 2.7 TDi | [BSG] | 01.2004- |
| AUDI | A6 2.7 TDi Quattro | [BPP] | 01.2004- |
| AUDI | A6 2.7 TDi Quattro | [BSG] | 01.2004- |
| SEAT | Alhambra 2.0 TDi | [CFFA] | 06.2010-05.2011 |
| SEAT | Alhambra 2.0 TDi | [CFFE] | 05.2011- |
| SEAT | Alhambra 2.0 TDi 4x4 | [CFFB] | 05.2011- |
| SKODA | Superb 1.6 TDi | [CAYC] | 09.2010- |
| VW | CC 2.0 TDi | [CFFA] | 11.2011- |
| VW | CC 2.0 TDi | [CFFB] | 11.2011- |
| VW | CC 2.0 TDi | [CFGB] | 11.2011- |
| VW | CC 2.0 TDi | [CFGC] | 12.2012- |
| VW | CC 2.0 TDi | [CLLA] | 11.2011- |
| VW | CC 2.0 TDi 4 Motion | [CFFB] | 11.2011- |
| VW | CC 2.0 TDi 4-Motion | [CFGC] | 12.2012- |
| VW | Passat 2.0 TDi | [CFFB] | 01.2012- |
| VW | Passat 2.0 TDi 4 Motion | [CBAB] | 08.2009-01.2012 |
| VW | Passat 2.0 TDi 4-Motion | [CFFB] | 01.2012- |
| VW | Passat 2.0 TDi 4-Motion | [CFGB] | 01.2012- |
| VW | Passat 2.0 TDi Blue | [CBAC] | 05.2009- |
| VW | Sharan 2.0 TDi | [CFFA] | 05.2010- |
| VW | Sharan 2.0 TDi | [CFFE] | 05.2011- |
| VW | Sharan 2.0 TDi | [CFGB] | 08.2010- |
| VW | Sharan 2.0 TDi 4-Motion | [CFFA] | 05.2011-05.2012 |
| VW | Sharan 2.0 TDi 4-Motion | [CFFB] | 05.2011- |
Reference Information
| 03G903016A | VW |
| 03G903016AX | VW |
| 114831 | CARGO |
| 2015176 | SANDO |
| 20444N | WAI / TRANSPO |
| 20444R | WAI / TRANSPO |
| 205.532.180 | PSH |
| 205.532.180.004 | PSH |
| 205.532.180.460 | PSH |
| 205.532.180.461 | PSH |
| 209423 | ERA |
| 2542827 | VALEO |
| 2543374 | VALEO |
| 28-5788 | ELSTOCK |
| 301910RI | KUHNER |
| 301910RIV | KUHNER |
| 32000017 | HERTH+BUSS |
| 3G903016A | VW |
| 3G903016AX | VW |
| 437542 | VALEO |
| 439549 | VALEO |
| 441921 | LOGISTIK |
| 542827 | VALEO |
| 55151106 | MEAT & DORIA |
| 57422 | EAI |
| 8EL012429-811 | HELLA |
| 8EL738211-691 | HELLA |
| A12VA0503AS | SIDAT |
| A131.506 | PSH |
| A146.733 | PSH |
| A148.453 | PSH |
| A3209S | AS-PL |
| AEK3176 | AUTOELECTRO |
| ALT00582 | ELECTROLOG |
| ALT2376CP | ROLLCO |
| ALTL757 | 3EFFE |
| ANM32422X | ANDEL |
| CA1910IR | HC PARTS |
| CAL15176 | CASCO |
| CAL15176AS | CASCO |
| CAL15176ES | CASCO |
| CAL15176GS | CASCO |
| CAL15176OS | CASCO |
| CAL15176RS | CASCO |
| F032114831 | CARGO |
| LRA03176 | LUCAS |
| LRA3176 | LUCAS |
| TG17C024 | VALEO |
| TG17C054 | VALEO |
| UD13410A | AS-PL |
| VALTG17C054 | WOODAUTO |
Video/Publications
