Brand new AS-PL Alternator
STANDARD LINE
AS-PL
VALEO
Price:
NZ$ 503.68 including GST
NZ$ 437.98 excluding GST
or four payments of $125.92
with
Learn More
each
A0533S
A3216
No stock in NZ - Call us for possible procurement options
No stock in NZ - Call us for possible procurement options
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
TG14C023Associated Numbers
0124525146 03L903023P 03L903023PX 03L903024B 06F903023N 06F903023P 2015456 20179654OE 2113671402 2616267A 28-5853 301782RI 301782RIB 301782RIV 439608 439753 440240 440343 553483RI 553483RIV 8EL012240-171 8EL012240-361 9215305 A3216 AEC1782 CAL15456GS EAA-222429 LRA03241 TG14C023 TG14C034 TG14C050 UD02264A VXA053
Specifications
| Amp | 140 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8.50 mm |
| Diameter (D.2) | 8.50 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Length (L.1) | 195 mm |
| Mount Inside Length or Pad Mount C-C (C) | 61 mm |
| OEM Product | No |
| Plug Code | PL_2300 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 49.50 mm |
| Pulley to Mount Distance (A) | 39 mm |
| Pulley Type | Clutch |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A3 3.2 quattro | [BDM] | 01.2003-12.2005 |
| AUDI | A3 3.2 quattro | [BMJ] | 01.2003-12.2005 |
| AUDI | TT 3.2 Quattro | [BUB] | 01.2006-12.2010 |
| SEAT | Exeo 2.0 TDi | [CA..] | 01.2009- |
| SEAT | Exeo 2.0 TDi | [CG..] | 01.2009- |
| SEAT | Exeo 2.0 TDi | [CJ..] | 01.2009- |
| SEAT | Exeo 2.0 TDi ST | [CA..] | 01.2009- |
| SEAT | Exeo 2.0 TDi ST | [CG..] | 01.2009- |
| SEAT | Exeo 2.0 TDi ST | [CJ..] | 01.2009- |
| SKODA | Superb 1.6 TDi | [CAYB] | 01.2010- |
| SKODA | Superb 1.6 TDi | [CAYC] | 01.2010- |
| SKODA | Superb 1.9 TDi | [BLS] | 01.2008- |
| SKODA | Superb 1.9 TDi | [BXE] | 01.2008- |
| SKODA | Superb 2.0 TDi | [BMP] | 01.2008- |
| SKODA | Superb 2.0 TDi | [CBBB] | 01.2008- |
| SKODA | Superb 2.0 TDi | [CFFB] | 01.2010- |
| SKODA | Superb 2.0 TDi | [CFGB] | 01.2010- |
| SKODA | Superb 2.0 TDi | [CLJA] | 01.2010- |
| SKODA | Superb 2.0 TDi 4x4 | [CBBB] | 01.2008- |
| SKODA | Superb 2.0 TDi 4x4 | [CFFB] | 01.2010- |
| SKODA | Superb 2.0 TDi 4x4 | [CFGB] | 01.2010- |
| SKODA | Superb 2.0 TDi 4x4 | [CLJA] | 01.2010- |
| SKODA | Superb 3.6 V6 4x4 | [CDVA] | 01.2008- |
| VW | Amarok 2.0 TDi | [CDBA] | 01.2010- |
| VW | Amarok 2.0 TDi | [CDCA] | 01.2010- |
| VW | Amarok 2.0 TDi | [CNEA] | 01.2010- |
| VW | Amarok 2.0 TDi | [CNEA] | 01.2012- |
| VW | Amarok 2.0 TDi | [CNFA] | 01.2010- |
| VW | Amarok 2.0 TDi | [CNFB] | 01.2012- |
| VW | Amarok 2.0 TDi | [CSHA] | 01.2010- |
| VW | Amarok 2.0 TDi | [CSHA] | 01.2012- |
| VW | Amarok 2.0 TDi 4-Motion | [CDBA] | 01.2010- |
| VW | Amarok 2.0 TDi 4-Motion | [CDCA] | 01.2010- |
| VW | Amarok 2.0 TDi 4-Motion | [CNEA] | 01.2010- |
| VW | Amarok 2.0 TDi 4-Motion | [CNEA] | 01.2012- |
| VW | Amarok 2.0 TDi 4-Motion | [CNFA] | 01.2010- |
| VW | Amarok 2.0 TDi 4-Motion | [CNFB] | 01.2012- |
| VW | Amarok 2.0 TDi 4-Motion | [CSHA] | 01.2010- |
| VW | Amarok 2.0 TDi 4-Motion | [CSHA] | 01.2012- |
| VW | Crafter 2.0 TDi | [CKTB] | 01.2011- |
| VW | Crafter 2.0 TDi | [CKTC] | 01.2011- |
| VW | Crafter 2.0 TDi | [CKUB] | 01.2011- |
| VW | Crafter 2.0 TDi | [CKUC] | 01.2011- |
| VW | Eos 3.2 V6 | [BUB] | 01.2006- |
| VW | Eos 3.2 V6 | [CBRA] | 01.2006- |
| VW | Eos 3.2 V6 | [CDVA] | 01.2006- |
| VW | Multivan 2.0 TDi | [CAA] | 01.2009- |
| VW | Multivan 2.0 TDi | [CCH] | 01.2009- |
| VW | Multivan 2.0 TDi | [CFCA] | 01.2009- |
| VW | Multivan 2.0 TDi 4-Motion | [CAA] | 01.2009- |
| VW | Passat 3.6 R36 | [BWS] | 01.2007- |
| VW | Transporter 2.0 TDi | [CAA] | 01.2009- |
| VW | Transporter 2.0 TDi 4Motion | [CAA] | 01.2009- |
| VW | Transporter 2.0 TDi 4Motion | [CAA] | 01.2009- |
Reference Information
| 0124525146 | BOSCH |
| 03L903023C | VW |
| 03L903023C | VW |
| 03L903023C | VW |
| 03L903023CX | VW |
| 03L903023P | VW |
| 03L903023PX | VW |
| 03L903024B | VW |
| 03L903024S | VW |
| 03L903024SX | VW |
| 04B903023A | VW |
| 06F903023N | VW |
| 06F903023P | VW |
| 06F903023PX | VW |
| 115730 | CARGO |
| 2015456 | SANDO |
| 20179654OE | REAL |
| 209104 | ERA |
| 2113671402 | DRI |
| 2616267A | VALEO |
| 28-5853 | ELSTOCK |
| 3L903023C | VW |
| 3L903023C | VW |
| 3L903023C | VW |
| 3L903023P | VW |
| 3L903023P | VW |
| 3L903023P | VW |
| 3L903023PX | VW |
| 3L903024B | VW |
| 439608 | VALEO |
| 439753 | VALEO |
| 440240 | VALEO |
| 440343 | VALEO |
| 442448 | LOGISTIK |
| 553483RI | KUHNER |
| 553483RIV | KUHNER |
| 6F903023P | VW |
| 6F903023P | VW |
| 6F903023P | VW |
| 8EL012240-171 | HELLA |
| 8EL012240-361 | HELLA |
| 9215305 | POWERMAX |
| A3216 | AS-PL |
| AEC1782 | AUTOELECTRO |
| ALT00524 | ELECTROLOG |
| ALT00616 | ELECTROLOG |
| ALT00798 | ELECTROLOG |
| ALT10230 | ELECTROLOG |
| ALTS366 | 3EFFE |
| CA2136IR | HC PARTS |
| CAL15456GS | CASCO |
| F000BL0895 | FIAT |
| F032115730 | CARGO |
| HVW0009060700 | MERCEDES |
| LRA03241 | LUCAS |
| LRA3241 | LUCAS |
| STX102238 | STARDAX |
| STX102241 | STARDAX |
| STX102245 | STARDAX |
| STX102245R | STARDAX |
| TG14C023 | VALEO |
| TG14C034 | VALEO |
| TG14C050 | VALEO |
| UD02264A | AS-PL |
Video/Publications
