Brand new AS-PL Alternator
STANDARD LINE
AS-PL
VALEO
Price:
NZ$ 572.00 including GST
NZ$ 497.39 excluding GST
or four payments of $143.00
with
Learn More
each
A3284
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
TG12C063Associated Numbers
0141541402 0986UR6272 115810 2015493 20179394OE 28-6591 439678 440263 4824 553569RIV 555.584.120.500 89215591 8EL012240-151 9090606 A0141541402 AEK3506 CAL15493GS DRA0984 LRA03481 TG12C063 UD12527ASpecifications
| Amp | 120 A |
| Diameter (D.1) | 9.50 mm |
| Diameter (D.2) | 9.50 mm |
| Diameter (D.3) | 9.50 mm |
| Diameter (D.4) | 9.50 mm |
| Length (L.1) | 199 mm |
| Mount Inside Length or Pad Mount C-C (C) | 57 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 70 mm |
| Pad mount thickness (E.2) | 70 mm |
| Plug Code | PL_2306 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 50 mm |
| Pulley to Mount Distance (A) | 33 mm |
| Pulley Type | Clutch |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| MERCEDES BENZ | C 180 1.8 CGi | [M271.820] | 01.2007- |
| MERCEDES BENZ | C 200 1.8 CGi | [M271.820] | 01.2009- |
| MERCEDES BENZ | C 250 1.8 CGi | [M271.860] | 01.2009- |
| MERCEDES BENZ | E 200 1.8 CGi | [M271.820] | 01.2010- |
| MERCEDES BENZ | E 200 1.8 CGi | [M271.860] | 01.2010- |
| MERCEDES BENZ | E 250 1.8 CGi | [M271.860] | 01.2009- |
| MERCEDES BENZ | SLK 200 1.8 | [M271.860] | 01.2011- |
| MERCEDES BENZ | SLK 200 1.8 | [M271.861] | 01.2011- |
| MERCEDES BENZ | SLK 250 1.8 | [M271.861] | 01.2011- |
Reference Information
| 0141541402 | MERCEDES |
| 0986UR6272 | BOSCH |
| 115810 | CARGO |
| 2015493 | SANDO |
| 20179394OE | REAL |
| 209221 | ERA |
| 28-6591 | ELSTOCK |
| 439678 | VALEO |
| 440263 | VALEO |
| 442505 | LOGISTIK |
| 4824 | CEVAM |
| 55151117 | MEAT & DORIA |
| 553569RIV | KUHNER |
| 555.584.120.500 | PSH |
| 89215591 | POWERMAX |
| 8EL012240-151 | HELLA |
| 9090606 | FRIESEN |
| A0141541402 | MERCEDES |
| A12VA0563AS | SIDAT |
| A3284 | AS-PL |
| ALT00143 | ELECTROLOG |
| ALTS634 | 3EFFE |
| ANM33204X | ANDEL |
| CAL15493GS | CASCO |
| DRA0984 | DELCO |
| F032115810 | CARGO |
| LRA03481 | LUCAS |
| LRA3481 | LUCAS |
| STX102165 | STARDAX |
| TG12C063 | VALEO |
| UD12527A | AS-PL |
