Brand new AS-PL Alternator
STANDARD LINE
AS-PL
VALEO
Price:
NZ$ 399.26 including GST
NZ$ 347.18 excluding GST
or four payments of $99.82
with
Learn More
each
A3220
A3331
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Information
TG9S019Associated Numbers
063731963010 0986080680 115531 165.502.080 2015318 209143 23100-AX610 23100-AX620 23100-AX62A 23560N 28-4903 301963RI 301963RIR 301963RIV 437543 439550 57061 600000164220 89212566 8EL012430-031 8EL738211-941 9238 944390904020 A3220 AEK2559 AG0997 ALV1963 CA1963IR CAL15318 CAL15318AS CAL15318ES CAL15318GS CAL15318OS CAL15318RS DA1316 DRA0206 EAA-222394 LRA02559 MRA90402 RAA11317 TG8S019 UD02318A UD12153A VAL439550Specifications
| Amp | 80 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | 10.50 mm |
| Diameter (D.2) | 10.50 mm |
| Diameter (D.3) | M10x1.25 mm |
| Length (L.1) | 169 mm |
| Mount Inside Length or Pad Mount C-C (C) | 70 mm |
| OEM Product | No |
| Plug Code | PL_2400 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 4 qty |
| Pulley Outside Diameter (O.D.1) | 55 mm |
| Pulley to Mount Distance (A) | 46 mm |
| Pulley Type | Solid |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| NISSAN | Micra 1.0 16V | [CG10DE] | 01.2003-06.2010 |
| NISSAN | Micra 1.2 16V | [CG12DE] | 01.2003-06.2010 |
| NISSAN | Micra 1.2 16V | [CR12DE] | 01.2003-06.2010 |
| NISSAN | Micra 1.4 16V | [CR14DE] | 01.2003-06.2010 |
| NISSAN | Micra 1.4 16V | [CR14DE] | 08.2005- |
| NISSAN | Note 1.4 | [CR14DE] | 03.2006- |
Reference Information
| 063731963010 | MAGNETI MARELLI |
| 0986080680 | BOSCH |
| 115531 | CARGO |
| 165.502.080 | PSH |
| 2015318 | SANDO |
| 209143 | ERA |
| 210516 | ERA |
| 23100-AX610 | NISSAN |
| 23100AX62 | NISSAN |
| 23100-AX620 | NISSAN |
| 23100-AX62A | NISSAN |
| 23100AX62B | NISSAN |
| 23560N | WAI / TRANSPO |
| 28-4903 | ELSTOCK |
| 301963RI | KUHNER |
| 301963RIR | KUHNER |
| 301963RIV | KUHNER |
| 437543 | VALEO |
| 439550 | VALEO |
| 442495 | LOGISTIK |
| 57061 | EAI |
| 600000164220 | MAGNETI MARELLI |
| 89212566 | POWERMAX |
| 8EL012430-031 | HELLA |
| 8EL738211-941 | HELLA |
| 9238 | CEVAM |
| 944390904020 | MAGNETI MARELLI |
| A12VA1182A2 | SIDAT |
| A130.616 | PSH |
| A146.921 | PSH |
| A3220 | AS-PL |
| AEK2559 | AUTOELECTRO |
| AG0997 | GHIBAUDI |
| ALT0077 | ELECTROLOG |
| ALT0098 | ELECTROLOG |
| ALT173180 | SIOM |
| ALTL626 | 3EFFE |
| ALV1963 | KRAUF |
| CA1963IR | HC PARTS |
| CAL15318 | CASCO |
| CAL15318AS | CASCO |
| CAL15318ES | CASCO |
| CAL15318GS | CASCO |
| CAL15318OS | CASCO |
| CAL15318RS | CASCO |
| DA1316 | DELCO |
| DRA0206 | DELCO |
| F032115531 | CARGO |
| LRA02559 | LUCAS |
| LRA2559 | LUCAS |
| MRA90402 | MAGNETI MARELLI |
| RAA11317 | DELCO |
| STX100557 | STARDAX |
| STX100557R | STARDAX |
| TG8S019 | VALEO |
| TG9S019 | VALEO |
| UD02318A | AS-PL |
| UD12153A | AS-PL |
| VAL439550 | WOODAUTO |
Video/Publications
A3331Related Items
