Associated Numbers
0986039891 1058821 1073049 11.1085 112698 20110287 21288N 2320 28-2637 28-2798 2871A167 301085RIM 35000195 437774 440024 4523 5030343 54022549 56568 56767 63221344 63321324 63321343 63321344 63321422 63321465 63321473 63341343 63341344 714-32300 7312901 89213180 8EL737034-001 9039891 943341343 95GB10300LA 95GB10300LB 95GB10300MA 95GB10300MB AEA2287 ALT12022 CA1085IR DRA9891 EAA-221537 LRB00287 LRB00288 R95GB10300MA R95GB10300MB SA078Specifications
Amp | 100 A |
Bottom Mounting Foot Width (B) | 13 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 8.5 mm |
Diameter (D.3) | 8.5 mm |
Grooves | 6 qty |
Length (L.1) | 181 mm |
Mount Inside Length or Pad Mount C-C (C) | 83.5 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 59.5 mm |
Plug Code | PL_9109 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 34 mm |
Pulley Type | SOLID |
Unit Type | LUCAS/MARELLI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FORD | Scorpio 2.9 i | [BRG] | 02.1995-12.1998 |
FORD | Scorpio 2.9 i 24V | [BOB] | 10.1994-12.1998 |
Reference Information
714-32300 1073049 AEA2287 ALTS993 21288N 8EL737034-001 EAA-221537 95GB10300LB 95GB10300LA 35000195 437774 4523 7312901 ANM32111X STA0245R 301085RIM 11.1085 63321473 63341343 0986039891 943341343 DRA9891 SA078 95GB10300MB 95GB10300MA 63321343 714-32200 5030343 63321344 63321465 63321422 LRB00288 LRB00287 1058821 54022549 R95GB10300MB 986039891 20110287 28-2798 28-2637 63221344 63341344 CA1085IR ALT12022 112698 LRB288 9039891 LRB287 714-40155 440024 714-40153 714-40154 R95GB10300MA 56568 2871A167 56767 89213180 63321324Video/Publications
0986039891 1058821 1073049 11.1085 112698 20110287 21288N 2320 28-2637 28-2798 2871A167 301085RIM 35000195 437774 440024 4523 5030343 54022549 56568 56767 63221344 63321324 63321343 63321344 63321422 63321465 63321473 63341343 63341344 714-32300 7312901 89213180 8EL737034-001 9039891 943341343 95GB10300LA 95GB10300LB 95GB10300MA 95GB10300MB AEA2287 ALT12022 ALTS993 CA1085IR DRA9891 EAA-221537 LRB00287 LRB00288 LRB287 LRB288 R95GB10300MA R95GB10300MB SA078Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Alternators.
