Brand new AS-PL Alternator
STANDARD LINE
AS-PL
MAGNETI MARELLI
Price:
NZ$ 372.76 including GST
NZ$ 324.14 excluding GST
or four payments of $93.19
with
Learn More
each
A4089
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
1022118355Associated Numbers
102211-8351 102211-8352 102211-8353 102211-8354 102211-8355 11.1925 1305962 1322573 1361259 1426014 1511220 2030173 24013N 24013R 301340RI 301340RID 301925RI 301925RID 3N1110300AB 3N1110300AC 3N1110300AD 3N1110300AE 3N1110300AF 4887 57243 595.548.105 89213291 8EL012428-421 9090566 A4089 CA1925IR CAL30173GS EAA-221629Specifications
| Amp | 105 A |
| Diameter (D.1) | 9.50 mm |
| Diameter (D.2) | 12.50 mm |
| Diameter (D.3) | 12.50 mm |
| Length (L.1) | 165 mm |
| Mount Inside Length or Pad Mount C-C (C) | 54 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 72 mm |
| Plug Code | PL_3402 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 48 mm |
| Pulley to Mount Distance (A) | 14 mm |
| Pulley Type | Solid |
| Unit Type | MAGNETI MARELLI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | C-Max 1.6 | 02.2007- | |
| FORD | Focus 1.4 | [ASDA] | 11.2004- |
| FORD | Focus 1.4 | [ASDB] | 11.2004- |
| FORD | Focus 1.6 | [FYD] | 09.2000-08.2003 |
| FORD | Focus 1.6 | [HWDA] | 11.2004- |
| FORD | Focus 1.6 | [HWDB] | 11.2004- |
| FORD | Focus 1.6 | [SHDA] | 11.2004- |
| FORD | Focus 1.6 C-Max | [HWDA] | 10.2003-03.2007 |
| FORD | Focus 1.6 C-Max | [HWDB] | 10.2003-03.2007 |
| FORD | Focus 1.6 FlexFuel | [FYDH] | 01.2002-11.2004 |
| FORD | Focus 1.6 Ti | [HXDA] | 11.2004- |
| FORD | Focus 1.6 Ti C-Max | [HXDA] | 08.2004-03.2007 |
Reference Information
| 102211-8351 | DENSO |
| 102211-8352 | DENSO |
| 102211-8353 | DENSO |
| 102211-8354 | DENSO |
| 102211-8355 | DENSO |
| 11.1925 | LAUBER |
| 1305962 | FORD |
| 1322573 | FORD |
| 1361259 | FORD |
| 1426014 | FORD |
| 1511220 | FORD |
| 1708472 | FORD |
| 2030173 | SANDO |
| 210357 | ERA |
| 24013N | WAI / TRANSPO |
| 24013R | WAI / TRANSPO |
| 301340RI | KUHNER |
| 301340RID | KUHNER |
| 301925RI | KUHNER |
| 301925RID | KUHNER |
| 3N1110300AA | FORD |
| 3N1110300AB | FORD |
| 3N1110300AC | FORD |
| 3N1110300AD | FORD |
| 3N1110300AE | FORD |
| 3N1110300AF | FORD |
| 3N1110300AG | FORD |
| 3N1110300EB | FORD |
| 442470 | LOGISTIK |
| 4887 | CEVAM |
| 5530352 | MEAT & DORIA |
| 57243 | EAI |
| 595.548.105 | PSH |
| 89213291 | POWERMAX |
| 8EL012428-421 | HELLA |
| 9090566 | FRIESEN |
| A12DE0087A2 | SIDAT |
| A4089 | AS-PL |
| AAL1045 | APEC |
| ALT134 | ROLLCO |
| ALT2018 | ROLLCO |
| ALT321730 | SIOM |
| ALT6549 | ELECTROLOG |
| ALTS263 | 3EFFE |
| CA1925IR | HC PARTS |
| CAL30173GS | CASCO |
| EZ4106 | ELTA AUTOMOTIVE |
| MS1022118354 | DENSO |
| NPANAL1045 | NAPA |
| RNL102211-8355 | RNL |
| STA0531R | BOVEZ |
| STX100470 | STARDAX |
| STX100470R | STARDAX |
| STX100677 | STARDAX |
| STX100677R | STARDAX |
Video/Publications
