Associated Numbers
20104791BN 20104791RC 2030197 28-4827 31400-80E10 31400-83E10 553084RI 63321774 63321832 AEK2330 CAL30197AS CAL30197RS LRA02330 SA925Specifications
| Amp | 60 A |
| Bottom Mounting Foot Width (B) | 58 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10 mm |
| Grooves | 4 qty |
| Length (L.1) | 170 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 55 mm |
| Plug Code | PL_9104 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 90 mm |
| Pulley Type | SOLID |
| Unit Type | LUCAS/MARELLI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SUZUKI | Swift 1.0 | [G10A] | 01.1996- |
| SUZUKI | Swift 1.3 | [G13BB] | 01.2001- |
Reference Information
CAL30197RS 63321774 20104791RC 28-4827 20104791BN 31400-80E10 LRA2330 LRA02330 31400-83E10 AEK2330 2030197 CAL30197AS 114894 A4097 ALTS508 5530952 A12MA0712A2 ALT9057 63321832 553084RI SA925Video/Publications
114894 20104791BN 20104791RC 2030197 28-4827 31400-80E10 31400-83E10 553084RI 63321774 63321832 AEK2330 ALTS508 CAL30197AS CAL30197RS LRA02330 LRA2330 SA925Add Your Number
