Brand new AS-PL Alternator
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 370.32 including GST
NZ$ 322.02 excluding GST
or four payments of $92.58
with
Learn More
each
A4104
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
101210-1480Associated Numbers
101210-1480 20104381OE 2030183 28-4946 46736968 51859049 553107RI 553107RIM 63321760 8EL012240-811 AEA1248 CA2059IR CAL30183 CAL30183AS CAL30183ES CAL30183GS CAL30183OS CAL30183RS DAN631 DRA0141 EAA-212126 LRA02828 UD12114A UD13548ASpecifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 33 mm |
| Diameter (D.1) | 10.50 mm |
| Diameter (D.2) | 11.50 mm |
| Diameter (D.3) | 8.50 mm |
| Length (L.1) | 186 mm |
| OEM Product | No |
| Plug Code | PL_9104 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 4 qty |
| Pulley Outside Diameter (O.D.1) | 60 mm |
| Pulley to Mount Distance (A) | 56 mm |
| Pulley Type | Solid |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FIAT | Seicento 1.1 | [176B2.000] | 01.1998-01.2010 |
| FIAT | Seicento 1.1 | [187A1.000] | 01.1998-01.2010 |
Reference Information
| 101210-1480 | DENSO |
| 20104381OE | REAL |
| 2030183 | SANDO |
| 210666 | ERA |
| 23828N | WAI / TRANSPO |
| 28-4946 | ELSTOCK |
| 442274 | LOGISTIK |
| 46736968 | FIAT |
| 51859049 | FIAT |
| 553107RI | KUHNER |
| 553107RIM | KUHNER |
| 63321760 | MAGNETI MARELLI |
| 71721144 | FIAT |
| 8EL012240-811 | HELLA |
| A12MA1141A2 | SIDAT |
| AEA1248 | AUTOELECTRO |
| ALT321830 | SIOM |
| ALT6581 | ELECTROLOG |
| ALTL797 | 3EFFE |
| ANM32361X | ANDEL |
| AX 1338 | STARLINE |
| CA2059IR | HC PARTS |
| CAL30183 | CASCO |
| CAL30183AS | CASCO |
| CAL30183ES | CASCO |
| CAL30183GS | CASCO |
| CAL30183OS | CASCO |
| CAL30183RS | CASCO |
| DAN631 | DENSO |
| DRA0141 | DELCO |
| LRA02828 | LUCAS |
| LRA2828 | LUCAS |
| STA0538R | BOVEZ |
| STX100424 | STARDAX |
| STX100424R | STARDAX |
| UD12114A | AS-PL |
| UD13548A | AS-PL |
Video/Publications
A4104View your shopping basket or Browse other items in Alternators.
