A4120 - Brand new AS-PL Alternator

Name: Brand new AS-PL Alternator
Brand: AS-PL
SKU: A4120
Price: 378.93 NZD
Availability: SoldOut

Brand new AS-PL Alternator

STANDARD LINE

Manufacturer:

AS-PL

Replacement For:

MAGNETI MARELLI

Price:

NZ$ 378.93 including GST

NZ$ 329.50 excluding GST

or four payments of $94.73 with
Learn More

UOM:

each

Product Code:

A4120

Quantity In Stock Nationally:

No stock in NZ - Call us for possible procurement options

Availability:

No stock in NZ - Call us for possible procurement options

Information
Associated Numbers
Specifications
Vehicle Applications
Reference Information
Video/Publications

63321493

20104861BN 2030168 30129RI 30129RIM 301435RI 301435RIM 30351RI 46446292 50012833 553000RI 63320112 63320125 63320128 63320141 63321015 63321028 63321080 63321410 63321493 71780127 7552284 7651812 CAL30168 CAL30168AS CAL30168ES CAL30168GS CAL30168OS CAL30168RS UD12925A

Amp	55 A
Bottom Mounting Foot Width (B)	16 mm
Diameter (D.1)	11 mm
Diameter (D.2)	12.50 mm
Diameter (D.3)	12.50 mm
Length (L.1)	183 mm
Mount Inside Length or Pad Mount C-C (C)	49 mm
OEM Product	No
Plug Code	PL_1200
Product Line	Standard Line
Product Type	Brand new
Pulley Grooves	5 qty
Pulley Outside Diameter (O.D.1)	62 mm
Pulley to Mount Distance (A)	54 mm
Pulley Type	Solid
Unit Type	MAGNETI MARELLI
Voltage	12 V

Make	Model	Type	Year
ABARTH	Ritmo 125 TC 2.0	[138AR1.000]	11.1981-12.1987
FIAT	124 Spider 2.0		04.1972-11.1985
FIAT	124 Spider 2000 2.0	[132C3.031]	04.1972-11.1985
FIAT	131 1.4 Mirafiori	[131C.000]	11.1980-01.1984
FIAT	131 1.4 Mirafiori	[131C.000]	11.1981-01.1984
FIAT	131 1.4 Mirafiori	[131C1.000]	11.1980-01.1984
FIAT	131 1.4 Mirafiori	[131C1.000]	11.1981-01.1984
FIAT	131 1.4 Mirafiori		11.1980-01.1984
FIAT	131 1.4 Super Mirafiori	[131C1.000]	04.1981-12.1983
FIAT	131 1.4 Super Mirafiori		04.1981-12.1983
FIAT	131 1.6	[131C2.000]	11.1976-12.1984
FIAT	131 1.6	[131C2.000]	11.1980-12.1984
FIAT	131 1.6		11.1976-12.1984
FIAT	131 2.0 Super	[131C4.000]	01.1981-12.1984
FIAT	131 2.0 Super		01.1981-12.1984
FIAT	132 1.6	[132BBOAO]	04.1972-01.1976
FIAT	132 1.6	[132C.000]	01.1976-12.1982
FIAT	132 1.6	[132C.000]	05.1977-09.1982
FIAT	132 1.6	[132C6.000]	03.1977-12.1981
FIAT	132 1.6		04.1972-12.1982
FIAT	132 2.0	[132C2.000]	01.1976-06.1981
FIAT	132 2.0	[D1.000]
FIAT	132 2.0 i.e.	[132C3.000]	01.1980-12.1982
FIAT	132 2.0 i.e.		01.1980-12.1982
FIAT	138 1.6	[AR.000]
FIAT	149 1.6	[A2.000]
FIAT	149 1.6	[A4.000]
FIAT	149 1.7	[B3.000]
FIAT	149 1.7	[B4.000]
FIAT	238 1.4	[131AZ.000]	09.1966-06.1976
FIAT	238 1.4		09.1966-06.1976
FIAT	Argenta 1.6		04.1981-12.1985
FIAT	Argenta 1600 2.0	[132D.000]	04.1981-12.1985
FIAT	Argenta 1600 i.e 2.0	[132D.000]	04.1981-12.1985
FIAT	Argenta 1.6 i.e.		04.1981-12.1985
FIAT	Argenta 2.0		06.1978-12.1985
FIAT	Argenta 2000 1.6 Volumex	[132C3.000]	06.1984-07.1985
FIAT	Argenta 2000 2.0	[132C2.000]	06.1978-12.1985
FIAT	Argenta 2000 2.0	[132D1.000]	06.1978-12.1985
FIAT	Argenta 2000 i.e. 1.6	[132C3.000]	06.1981-07.1986
FIAT	Argenta 2.0 i.e.		06.1981-
FIAT	Campagnola 2.0	[6132AZ2.000]	06.1974-10.1989
FIAT	Campagnola 2.0		06.1974-10.1989
FIAT	Croma 1.6		12.1985-12.1990
FIAT	Croma 1600 1.6	[154A.048]	12.1985-12.1990
FIAT	Croma 2.0		12.1985-02.1989
FIAT	Croma 2000 CHT 2.0	[154A1.000]	12.1985-02.1989
FIAT	Ducato 1.9 D	[149B1.000]	01.1988-08.1990
FIAT	Ducato 1.9 D	[149B1.000]	02.1987-08.1990
FIAT	Ducato 1.9 D	[149B1.000]	07.1990-03.1994
FIAT	Ducato 1.9 D		01.1988-08.1990
FIAT	Duna 1.7 DS	[149B3.000]	01.1987-12.1991
FIAT	Duna 1.7 DS		01.1987-12.1991
FIAT	Fiorino 1.7 D	[146B2.000]	10.1993-10.1999
FIAT	Fiorino 1.7 D	[149B3.000]	05.1988-10.1999
FIAT	Fiorino 60 1.7 D	[146B2.000]	05.1988-10.1996
FIAT	Fiorino 60 1.7 D	[149B3.000]	05.1988-05.2000
FIAT	Fiorino 60 1.7 D		05.1988-10.2000
FIAT	Regata 100 1.6	[149A4.000]	09.1984-12.1990
FIAT	Regata 100 1.6	[149C3.000]	09.1984-12.1990
FIAT	Regata 100 1.6 i RF		09.1984-12.1990
FIAT	Regata 100 Super 1.6	[149A2.000]	10.1983-12.1990
FIAT	Regata 100 Super 1.6	[149A4.000]	10.1983-12.1990
FIAT	Regata 100 Super 1.6		10.1983-12.1990
FIAT	Regata 60 1.7 D		05.1985-03.1989
FIAT	Regata 60 D 1.7	[149B3.000]	01.1984-12.1989
FIAT	Regata 60 D 1.7	[149B3.000]	05.1985-03.1989
FIAT	Regata 61 1.9 D		04.1984-07.1989
FIAT	Regata 65 1.9 D		04.1984-07.1989
FIAT	Regata 65 D 1.9	[149A1.000]	04.1984-07.1989
FIAT	Regata 85 1.6	[149A.000]	10.1983-06.1990
FIAT	Regata 85 1.6		10.1983-06.1990
FIAT	Regata 90 1.6 i.e		01.1987-07.1989
FIAT	Regata 90 i.e. 1.6	[149C2.000]	01.1987-07.1989
FIAT	Ritmo 1.6	[138AR.000]	05.1981-12.1987
FIAT	Ritmo 1.6		05.1981-12.1987
FIAT	Ritmo 1.7 D	[138A5.000]	10.1979-09.1982
FIAT	Ritmo 1.7 D	[138C.000]	05.1985-12.1987
FIAT	Ritmo 1.7 D	[149B3.000]	05.1985-12.1987
FIAT	Ritmo 1.7 D		05.1985-12.1987
FIAT	Talento 1.9 D	[149B1.000]	03.1989-03.1994
FIAT	Talento 1.9 D		03.1989-03.1994
FIAT	Tipo 1.7 D	[149B4.000]	01.1988-10.1994
FIAT	Tipo 1.7 D		01.1988-10.1994
FIAT	Uno 1.9 D	[149B5.046]	09.1989-03.1994
FIAT	Uno 1.9 D		09.1989-03.1994
FIAT	Uno 60 1.7 D		07.1986-12.1993
FIAT	Uno 60 D 1.7	[146B2.000]	09.1989-12.1993
FIAT	Uno 60 D 1.7	[149B3.000]	07.1986-08.1989
FIAT	Uno 70 TD 1.4	[146B.000]	10.1986-10.1990
FIAT	Uno 70 TD 1.4	[146B3.000]	10.1986-10.1990
FIAT	Uno 70 TD 1.4		10.1986-10.1990
INNOCENTI	146 1.7	[B2.000]
INNOCENTI	Elba 1.7 D	[146B2.000]	08.1991-12.1996
LANCIA	828 1.6	[B.000]
LANCIA	Beta 1300 1.3		04.1976-07.1982
LANCIA	Beta 1600 1.6	[828B.000]	08.1973-07.1982
LANCIA	Beta 2000 2.0	[828B1.000]	04.1976-12.1984
LANCIA	Beta H.P.E. 2000 2.0	[828B1.000]	04.1979-09.1984
LANCIA	Beta H.P.E. 2000 2.0	[828B1.000]	05.1976-05.1978
LANCIA	Delta 1.6 GT	[831A4.000]	11.1982-04.1986
LANCIA	Delta 1.6 HF Turbo	[831A7.000]	10.1983-12.1986
LANCIA	Prisma 1.6	[831A4.000]	01.1983-04.1986
LANCIA	Prisma 1.9 D	[831D.000]	01.1983-02.1992
PININFARINA	Spider Europa 2000 2.0	[132C3.031]	03.1982-09.1985
PININFARINA	Spider Europa 2000 2.0	[132C3.031]	11.1984-11.1985
SEAT	Ibiza 1.7 D	[022A.5000]	06.1984-05.1993
SEAT	Ibiza 1.7 D	[022A.5000]	08.1990-05.1993
SEAT	Malaga 1.7 D	[022A.5000]	05.1985-12.1993
SEAT	Malaga 1.7 D	[022A.5000]	05.1990-12.1993
SEAT	Ronda 1.7 D	[022A.5000]	06.1982-12.1986

063320112	MAGNETI MARELLI
063320112010	MAGNETI MARELLI
063320125	MAGNETI MARELLI
063320125010	MAGNETI MARELLI
063320128	MAGNETI MARELLI
063320128010	MAGNETI MARELLI
063320141	MAGNETI MARELLI
063320141010	MAGNETI MARELLI
063321015	MAGNETI MARELLI
063321015010	MAGNETI MARELLI
063321028	MAGNETI MARELLI
063321028010	MAGNETI MARELLI
063321080	MAGNETI MARELLI
063321080010	MAGNETI MARELLI
063321410	MAGNETI MARELLI
063321410010	MAGNETI MARELLI
063321493	MAGNETI MARELLI
063321493010	MAGNETI MARELLI
20104861BN	REAL
20104861OE	REAL
2030168.0	SANDO
2030168.1	SANDO
46446292	FIAT
46446293	FIAT
50012833	FIAT
553000RI	KUHNER
63320112	MAGNETI MARELLI
63320125	MAGNETI MARELLI
63320128	MAGNETI MARELLI
63320141	MAGNETI MARELLI
63321015	MAGNETI MARELLI
63321028	MAGNETI MARELLI
63321080	MAGNETI MARELLI
63321410	MAGNETI MARELLI
63321493	MAGNETI MARELLI
71780127	FIAT
7552284	FIAT
89212732	POWERMAX
A4120	AS-PL
ALT90091	ELECTROLOG
ALTL385	3EFFE
CAL30168AS	CASCO
CAL30168GS	CASCO
PRAL385	3EFFE
STX100296	STARDAX
STX100354	STARDAX
STX100354R	STARDAX
STX100898	STARDAX
STX100904	STARDAX
UD12925A	AS-PL

A4120
