Information
A5TG1191Associated Numbers
11253N 90-27-3372 A-80253 A5TG1191 UD11249A
A5TG1191, AMT0210
BOSCHA L4511X
J&N ELECTRICAL PRODUCTS 400-48096
LESTER 11253
MITSUBISHI A5TG1191
SUZUKI 31400-80J10, 31400-80J11
anj584gq anj584 65-6685-3
Specifications
Amp | 80 A |
Bottom Mounting Foot Width (B) | 61 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10.50 mm |
Length (L.1) | 162 mm |
OEM Product | No |
Plug Code | PL_4001 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Grooves | 5 qty |
Pulley Outside Diameter (O.D.1) | 55 mm |
Pulley to Mount Distance (A) | 91.50 mm |
Pulley Type | Solid |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
SUZUKI | SX4 2.0 | 01.2007- | |
SUZUKI | SX7 2.0 | 01.2006- | |
SUZUKI | SX8 2.0 | 01.2007-12.2010 |
Reference Information
11253N | WAI / TRANSPO |
90-27-3372 | WILSON |
A5TG1191 | MITSUBISHI |
A-80253 | DIXIE |
ALT5392 | ELECTROLOG |
STX102136 | STARDAX |
UD11249A | AS-PL |
