Associated Numbers
0986082000 11207 11377N 155.580.120 1800A053 20137152BN 2035251 28-6598 302013RI 89213042 90-27-3387 9090688 9430 A-80266 A003TG3181 A3TG3181 AEC2013 CA2013IR CAL35251AS DRA1004 LRA03488 UD11207A ASPL AUTOELECTRO BOSCH CASCO CEVAM DELCO A80266 DIXIE 286598 ELSTOCK FRIESEN HC PARTS LUCAS MITSUBISHI List POWERMAX PSH REAL WAI / TRANSPO 90273387 WILSON mxa2025 Bosch ruil 11377 Lester 155580120 Mitsubishi Wilson 9090688F Friesen 931004 EDR ALT5293sa Electrolog Remy KTR311160240 KTR Lucas Beck Arnley 1861383 A003TG3181MI M1800A053D PIC Picture ID 2035331 Light Duty 656688 anj567 anj567GQ 0986082001 115760 Cargo 12060994 EuroTec Elstock 5705KA PSA show ACA421 ATK F042205090 LRA3488 SP6464 Spidan References: 186-1383 203-5331 2013CAR RNL Sando 20352510 2263061202 DRI 287935 3112441 Henkel Parts 50103103 RE-EX 57616 EAI 931004N Dixie Auto Electro ALT31403 Wood AMI251A AutoTeam DA2114 DA2114N DRA1004N EAL5523 Kavo J5115090 Herth Buss MITA3TG3181 RNLA3TG3181 RNLA3TG3181NP WOOALT31403 65-6688 Arrowhead AMT0234 Ashdown Ingram MXA2025 BBB Industries Reman AL4253X Service Europe 0-986-CR6-319 0-986-UR6-319 Delco DENSO 210-4306 Electric Ltd CARGO CA2013 IAT A11377 Industry J&N 400-48171 (Europe) MPA NAPA 213-8856 Romaine 11377N-OEM USA A3377 Voltux V2-11377 V2-11377RSpecifications
| Amp | 120 A |
| Bottom Mounting Foot Width (B) | 13 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | 10.5 mm |
| Grooves | 6 qty |
| Length (L.1) | 181 mm |
| Mount Inside Length or Pad Mount C-C (C) | 54.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 55 mm |
| Plug Code | PL_4100 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 34 mm |
| Pulley Type | CLUTCH |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CITROEN | C-Crosser 2.0 | [4B11] | 01.2010- |
| CITROEN | C-Crosser 2.0 | [4B11] | 11.2010- |
| CITROEN | C-Crosser 2.0 AWD | [4B11] | 11.2010- |
| CITROEN | C-Crosser 2.4 | [4B12] | 01.2009- |
| CITROEN | C-Crosser 2.4 | [SFZ(4B12-MMC)] | 08.2008- |
| CITROEN | C-Crosser 2.4 16V | [SFZ(4B12)] | 01.2008- |
| MITSUBISHI | Asx 1.8 | [4B10] | 02.2010- |
| MITSUBISHI | ASX 1.8 | [4B10] | 01.2010- |
| MITSUBISHI | ASX 1.8 4WD | [4B10] | 01.2010- |
| MITSUBISHI | Asx 2.0 | [4B11] | 06.2010- |
| MITSUBISHI | Asx 2.0 | [4J11] | 06.2010- |
| MITSUBISHI | ASX 2.0 | [4B11] | 01.2010- |
| MITSUBISHI | Asx 2.0 4WD | [4B11] | 06.2010- |
| MITSUBISHI | Asx 2.0 4WD | [4J11] | 06.2010- |
| MITSUBISHI | ASX 2.0 4WD | [4B11] | 01.2010- |
| MITSUBISHI | Lancer 1.8 | [4B10] | 01.2007-12.2012 |
| MITSUBISHI | Lancer 1.8 | [4B10] | 02.2008- |
| MITSUBISHI | Lancer 1.8 | [4B10] | 05.2010- |
| MITSUBISHI | Lancer 1.8 | [4B10] | 11.2009- |
| MITSUBISHI | Lancer 1.8 Bifuel | [4B10] | 01.2010- |
| MITSUBISHI | Lancer 1.8 Bifuel Sportback | [4B10] | 02.2010- |
| MITSUBISHI | Lancer 1.8 Flexfuel | [4B10] | 01.2010- |
| MITSUBISHI | Lancer 1.8 Flexfuel | [4B10] | 03.2009- |
| MITSUBISHI | Lancer 1.8 Flex Sportback | [4B10] | 03.2009- |
| MITSUBISHI | Lancer 1.8 Sportback | [4B10] | 03.2009- |
| MITSUBISHI | Lancer 1.8 Sportback | [4B10] | 06.2008- |
| MITSUBISHI | Lancer 2.0 | [4B11] | 01.2008- |
| MITSUBISHI | Lancer 2.0 | [4B11] | 01.2009- |
| MITSUBISHI | Lancer 2.0 | [4B11] | 01.2013- |
| MITSUBISHI | Lancer 2.0 Evo X | [4B11-T/C] | 06.2008-12.2015 |
| MITSUBISHI | Lancer 2.0 i | [4B11] | 04.2007- |
| MITSUBISHI | Lancer 2.0 i 4WD | [4B11] | 03.2007- |
| MITSUBISHI | Lancer 2.0 i Ralliart 4WD | [4B11-T/C] | 10.2008- |
| MITSUBISHI | Lancer 2.0 Ralliart 4WD Sportback | [4B11-T/C] | 10.2008- |
| MITSUBISHI | Outlander 2.0 | [4B11] | 01.2006- |
| MITSUBISHI | Outlander 2.0 | [4B11] | 11.2006-11.2012 |
| MITSUBISHI | Outlander 2.0 4WD | [4B11] | 01.2006- |
| MITSUBISHI | Outlander 2.0 4WD | [4B11] | 11.2006-11.2012 |
| MITSUBISHI | Outlander 2.4 | [4B12] | 01.2006- |
| MITSUBISHI | Outlander 2.4 | [4B12] | 11.2006-11.2012 |
| MITSUBISHI | Outlander 2.4 4WD | [4B12] | 01.2006- |
| MITSUBISHI | Outlander 2.4 4WD | [4B12] | 09.2007-11.2012 |
| MITSUBISHI | Outlander 2.4 Flex 4WD | [4B12] | 09.2007-11.2012 |
| PEUGEOT | 4007 2.0 | [4B11] | 01.2010-12.2012 |
| PEUGEOT | 4007 2.0 | [4B11] | 11.2010-03.2013 |
| PEUGEOT | 4007 2.0 4x4 | [4B11] | 11.2010-03.2013 |
| PEUGEOT | 4007 2.4 | [SFY(4B12-MMC)] | 02.2007-03.2013 |
| PEUGEOT | 4007 2.4 | [SFZ(4B12-MMC)] | 02.2007-03.2013 |
| PEUGEOT | 4007 2.4 16V | [4B12] | 01.2008-12.2012 |
| PEUGEOT | 4008 2.0 AWC | [4B11] | 05.2012- |
Alternatives >>>
A5285 - Will replace A5242
Reference Information
A-80266 AEC2013 UD11207A MITA3TG3181 A12MH0675A2 ALM9013 A2TG2181 447035 LRA03488 ANM33224 115760 209640A CA2013IR DRA1004 CGB-86598 J5115090 11377R 986082000 90-27-3387 ALM2013 11377N ALT5293 28-6598 302013RI 9430 0986082000 DA2114N 2035251 155.580.120.608 20137152BN CAL35251AS DA2114 ANM33224X LRA3488 63732013010 A5242 155.580.120.138 ALT31403 5705KA A003TG3181 1800A053 155.580.120.130 89213042 DRA1004N ALT2210CP ALTL656 A3TG3181 A002TG2181Video/Publications
0986082000 11207 11377N 115760 12060994 155.580.120 20137152BN 2035251 2035251.0 28-6598 89213042 90-27-3387 9090688 9430 A-80266 A003TG3181 A3TG3181 A5242 AEC2013 ALM2013 ALM9013 ALT2210CP ALT31403 ALTL656 CA2013IR CAL35251AS DA2114 DA2114N DRA1004 DRA1004N J5115090 LRA03488 LRA3488 MITA3TG3181 UD11207AAdd Your Number
