Information
A3TB5291Associated Numbers
11029N 12584 90-27-3337 A-80238 A3TB5291 A3TB5291ZC A3TG2491 A3TG2491ZC UD11210ASpecifications
Amp | 110 A |
Diameter (D.1) | 12.50 mm |
Diameter (D.2) | 10.50 mm |
Diameter (D.3) | 10.50 mm |
Length (L.1) | 163 mm |
Mount Inside Length or Pad Mount C-C (C) | 74 mm |
OEM Product | No |
Pad mount thickness (E.1) | 47 mm |
Pad mount thickness (E.2) | 52 mm |
Pad mount thickness (E.3) | 52 mm |
Plug Code | PL_4100 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Grooves | 6 qty |
Pulley Outside Diameter (O.D.1) | 60 mm |
Pulley to Mount Distance (A) | 42.50 mm |
Pulley Type | Solid |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MITSUBISHI | Eclipse 3.8 | 01.2007-12.2012 | |
MITSUBISHI | Endeavor 3.8 | 01.2004-12.2012 | |
MITSUBISHI | Galant 3.8 | 01.2004-12.2009 |
Reference Information
11029N | WAI / TRANSPO |
12584 | DELCO |
90-27-3337 | WILSON |
A3TB5291 | MITSUBISHI |
A3TB5291ZC | MITSUBISHI |
A3TG2491 | MITSUBISHI |
A3TG2491ZC | MITSUBISHI |
A-80238 | DIXIE |
UD11210A | AS-PL |
Video/Publications
A5268Related Items
