Brand new AS-PL Alternator
STANDARD LINE
AS-PL
MITSUBISHI
Price:
NZ$ 390.15 including GST
NZ$ 339.26 excluding GST
or four payments of $97.54
with
Learn More
each
A5304
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Associated Numbers
12267 13840N 19134375 20130174 210-4159 210-4165 401523RI 401805RI 440121 90-27-3365 A002TA5393 A002TA5393ZC A002TA5394 A2TA5392 A2TA5393 A2TA5393ZC A2TA5394 A2TB7391 ALT31271 M317862D M343562D MD322925 MD357737 MD363639 MD363639D MD375853 MITA2TA5394 UD11225ASpecifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 13.50 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10.50 mm |
| Diameter (D.3) | 10.50 mm |
| Length (L.1) | 172 mm |
| Mount Inside Length or Pad Mount C-C (C) | 66 mm |
| OEM Product | No |
| Plug Code | PL_4100 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 5 qty |
| Pulley Outside Diameter (O.D.1) | 60 mm |
| Pulley to Mount Distance (A) | 37 mm |
| Pulley Type | Solid |
| Unit Type | MITSUBISHI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHRYSLER | Sebring 2.4 | [EDO] | 01.2001-12.2005 |
| CHRYSLER | Sebring 2.4 | [EDZ] | 01.2001-12.2005 |
| MITSUBISHI | Colt 1.3 16V | [4G13] | 01.2000-12.2003 |
| MITSUBISHI | Lancer 1.3 | [4G13] | 01.1995-12.2001 |
| MITSUBISHI | Mirage 1.5 | [4G15] | 01.1995-12.1999 |
Reference Information
| 002-C348 | ASHIKA |
| 002-C371 | ASHIKA |
| 002-C396 | ASHIKA |
| 12060706 | EUROTEC |
| 13840N | WAI / TRANSPO |
| 20137371BN | REAL |
| 2035173.0 | SANDO |
| 210611 | ERA |
| 210624 | ERA |
| 28-4800 | ELSTOCK |
| 2C348 | JAPKO |
| 2C371 | JAPKO |
| 2C396 | JAPKO |
| 401805RI | KUHNER |
| 471Q37019509 | MITSUBISHI |
| 476Q1L3701950 | MITSUBISHI |
| 89212584 | POWERMAX |
| 8EL012428-991 | HELLA |
| 8EL738211-061 | HELLA |
| 90-27-3365 | WILSON |
| 9051572 | FRIESEN |
| 944390515720 | MAGNETI MARELLI |
| A002TA5191 | MITSUBISHI |
| A002TA5192 | MITSUBISHI |
| A002TA5291 | MITSUBISHI |
| A002TA5393 | MITSUBISHI |
| A002TA5394 | MITSUBISHI |
| A002TA5394AM | MITSUBISHI |
| A003B2291ZC | MITSUBISHI |
| A12MH0665A2 | SIDAT |
| A2TA5191 | MITSUBISHI |
| A2TA5192 | MITSUBISHI |
| A2TA5192A | MITSUBISHI |
| A2TA5291 | MITSUBISHI |
| A2TA5393 | MITSUBISHI |
| A2TA5393ZC | MITSUBISHI |
| A2TA5394 | MITSUBISHI |
| A2TA5394AM | MITSUBISHI |
| A2TB5791 | MITSUBISHI |
| A2TB5791ZC | MITSUBISHI |
| A3TB2291ZC | MITSUBISHI |
| A5304 | AS-PL |
| A-80025 | DIXIE |
| ALC348 | JAPANPARTS |
| ALC371 | JAPANPARTS |
| ALC396 | JAPANPARTS |
| ALM1805 | KRAUF |
| ALM8805 | KRAUF |
| ALM9805 | KRAUF |
| ALT31271 | WOODAUTO |
| ALT371730 | SIOM |
| ALT530 | ROLLCO |
| ALT5443 | ELECTROLOG |
| ALTW284 | 3EFFE |
| CAL35173AS | CASCO |
| DA1224 | DELCO |
| DRA0114 | DELCO |
| J5115072 | HERTH+BUSS |
| JA1805IR | HC PARTS |
| LRA02310 | LUCAS |
| LRA2310 | LUCAS |
| MD325696 | MITSUBISHI |
| MD325697 | MITSUBISHI |
| MD334167 | MITSUBISHI |
| MD362870 | MITSUBISHI |
| MD363639 | MITSUBISHI |
| MD367214 | MITSUBISHI |
| MITA2TA5394 | WOODAUTO |
| MRA51572 | MAGNETI MARELLI |
| STX100438 | STARDAX |
| STX100601 | STARDAX |
| UD11225A | AS-PL |
Video/Publications
A5304Related Items
