Information
1042102320Associated Numbers
063377539010 0986082450 104210-2320 104210-2520 104210-2530 115657 195.936.100 20132733OE 2040337 20538R 210979 27060-0N040 27060-0N050 27060-33100 28-6773 553507RI 553507RID 89215412 9498 AEK3633 AG1163 ALN2320 ALT30521 CA2097IR CAL40337 CAL40337AS CAL40337ES CAL40337GS CAL40337OS CAL40337RS DA2396 DAN1018 DENDAN1018 DRA1286 EAA-222044 J5112180 LRA03633 LRA3633 MAN7539 RAA12397
|
063377539010 |
Magneti Marelli |
|---|---|
|
0986082450 |
Bosch Exchange |
|
1042102320 |
Denso |
|
1042102321 |
Denso |
|
1042102322 |
Denso |
|
1042102520 |
Denso |
|
1042102521 |
Denso |
|
1042102522 |
Denso |
|
1042102530 |
Denso |
|
1042102531 |
Denso |
|
1042102532 |
Denso |
|
115657 |
HC-Cargo |
|
195936100 |
PSH |
|
20201056 |
AES |
|
20538N |
WAI |
|
20538R |
WAI |
|
270600N040 |
Toyota |
|
270600N050 |
Toyota |
|
2706033100 |
Toyota |
|
270603310084 |
Toyota |
|
440853 |
Valeo |
|
440892 |
Valeo |
|
443067 |
Valeo |
|
63377539 |
Magneti Marelli |
|
ALT30521 |
Wood Auto |
|
ATA926 |
ATK |
|
CA2097IR |
HC-Parts |
|
DAN1018 |
Denso |
|
DENDAN1018 |
Wood Auto |
|
DRA0958 |
Delco Remy |
|
DRA1286 |
Delco Remy |
|
F032115657 |
HC-Cargo |
|
LRA03633 |
Lucas |
|
LRA3633 |
Lucas |
|
MAN7539 |
Magneti Marelli |
|
RAA12397 |
Delco Remy |
|
RNL1042102320 |
RNL |
|
TRA319 |
TWA |
|
WOOALT30521 |
Wood Auto |
Specifications
| Amp | 100 A |
| Bottom Mounting Foot Width (B) | 20.50 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.4) | M10x1.25 mm |
| Length (L.1) | 171 mm |
| Mount Inside Length or Pad Mount C-C (C) | 42.80 mm |
| OEM Product | No |
| Plug Code | PL_4002 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 57.90 mm |
| Pulley to Mount Distance (A) | 47 mm |
| Pulley Type | Clutch |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Auris 1.4 D-4D | [1ND-TV] | 03.2007-09.2012 |
| TOYOTA | Corolla 1.4 D-4D | [1ND-TV] | 10.2006- |
| TOYOTA | Urban Cruiser 1.4 D-4D | [1ND-TV] | 01.2009-04.2014 |
| TOYOTA | Urban Cruiser 1.4 D-4D 4WD | [1ND-TV] | 01.2009-04.2014 |
| TOYOTA | Yaris 1.4 D-4D | [1ND-TV] | 08.2005- |
Reference Information
| 063377539010 | MAGNETI MARELLI |
| 0986082450 | BOSCH |
| 104210-2320 | DENSO |
| 104210-2321 | DENSO |
| 104210-2322 | DENSO |
| 104210-2520 | DENSO |
| 104210-2521 | DENSO |
| 104210-2522 | DENSO |
| 104210-2530 | DENSO |
| 104210-2531 | DENSO |
| 104210-2532 | DENSO |
| 115657 | CARGO |
| 195.936.100.050 | PSH |
| 195.936.100.058 | PSH |
| 195.936.100.260 | PSH |
| 195.936.100.415 | PSH |
| 20132733BN | REAL |
| 20132733OE | REAL |
| 2040337.0 | SANDO |
| 2040337.1 | SANDO |
| 20538R | WAI / TRANSPO |
| 210979 | ERA |
| 27060-0N040 | TOYOTA |
| 27060-0N050 | TOYOTA |
| 27060-33100 | TOYOTA |
| 28-6773 | ELSTOCK |
| 446658 | LOGISTIK |
| 553507RI | KUHNER |
| 553507RID | KUHNER |
| 5540431 | MEAT & DORIA |
| 89215412 | POWERMAX |
| 8EL011712-931 | HELLA |
| 9498 | CEVAM |
| A12DE0495A2 | SIDAT |
| A6065 | AS-PL |
| AAL1225 | APEC |
| AEK3633 | AUTOELECTRO |
| AG1163 | GHIBAUDI |
| AI-90157 | AINDE |
| ALN2320 | KRAUF |
| ALT2189CP | ROLLCO |
| ALT30521 | WOODAUTO |
| ALT423370 | SIOM |
| ALT6353 | ELECTROLOG |
| ALTL821 | 3EFFE |
| CA2097IR | HC PARTS |
| CAL40337AS | CASCO |
| CAL40337GS | CASCO |
| CGB-86773 | AINDE |
| DA2396 | DELCO |
| DAN1018 | DENSO |
| DENDAN1018 | WOODAUTO |
| DRA1286 | DELCO |
| F032115657 | CARGO |
| J5112180 | HERTH+BUSS |
| LRA03633 | LUCAS |
| LRA3633 | LUCAS |
| MAN7539 | MAGNETI MARELLI |
| NPANAL1225 | NAPA |
| PRAL821 | 3EFFE |
| RAA12397 | DELCO |
| RNL104210-2320 | RNL |
| STX110224 | STARDAX |
| STX110224R | STARDAX |
| UD101263A | AS-PL |
