Associated Numbers
101210-1720 28-6958 554330RID 9606007480 9688237380 DAN1071 DENDAN1071 DRA1104Specifications
Amp | 90 A |
Bottom Mounting Foot Width (B) | 21 mm |
Diameter (D.1) | 10.5 mm |
Diameter (D.2) | 10 mm |
Diameter (D.3) | M10x1.5 mm |
Diameter (D.4) | M10x1.5 mm |
Grooves | 6 qty |
Length (L.1) | 177 mm |
Mount Inside Length or Pad Mount C-C (C) | 46 mm |
OEM Product | Yes |
Outside Diameter (O.D.1) | 54 mm |
Plug Code | PL_2402 |
Product Line | Premium Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 42 mm |
Pulley Type | CLUTCH |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
PEUGEOT | 208 1.0 | 03.2012- | |
PEUGEOT | 208 1.2 | 03.2012- |
Reference Information
9606007480 225.564.090.260 A12DE1243A2 MS1012101721 20132863BN 554330RID 0F000BL07VD 210946 9688237380 986083390 2040368.1 442613 28-6958 DRA1104 554330RI 1610048280 DENDAN1071 225.564.090.280 F000BL07VD 20132863OE ALT6143 DAN1071 225.564.090.050 2040368 1608066080 0986083390 CAL40368GS 32083390 9806007480 101210-1720 101210-1721 CAL40368ASVideo/Publications
0986083390 101210-1720 28-6958 32083390 554330RID 9606007480 9688237380 9806007480 DAN1071 DENDAN1071 DRA1104 210946Add Your Number
