Associated Numbers
0986049840 100210-3270 100210-3350 100210-3360 100210-3400 100210-3460 100210-3580 100210-3680 100210-3770 100210-3810 100210-3820 100210-3821 111483 20130103 20130104 27-1802 27020-54250 27020-54351 27020-54352 27020-54353 27020-54354 27020-54383 27030-54190 27030-54241 27030-54242 27030-54243 27030-54244 27030-54250 27030-54260 27030-54261 27030-54262 27030-54263 40193 40777 A6139 AEB0777 ALN8868 ALT30052 J2702054352 J2702054700 JA777 LRA01096 27020-54344 DXA4102 14-004 Ashdown Alternator 903-70830X Auto Electrics Australia ALT2830 12v Daihatsu 27030-87602-000 Denso 021000-0830 55amps 021000-2680 021000-8830 [27020-54021] 40amps 021000-9950 [27020-56160] 09816105 100210-0283 [27030-68110] 100210-0510 [27030-47033] 100210-0512 100210-1451 [27030-47034] 50amps 100210-1461 100210-1555 [27030-54013] 100210-1560 [27030-87311] 35amps 100210-1562 100210-1573 [27030-54022] 100210-1951 100210-2260 100210-2350 [27030-54090] 100210-2380 [27030-54120] 100210-2461 100210-2600 [27030-54130] 100210-2620 [27030-64040] 100210-2660 [27030-54140] 100210-2700 [27030-54150] 45amps 100210-2750 [27030-54160] 100210-2830 100210-2840 [27030-87602-000] 100210-2850 100210-2870 60amps 100210-2871 100210-3080 [27030-54218] [27030-54190] [27030-54241] [27030-54242] 100210-3720 [27030-87603] 100210-9920 100211-1460 [MD089595] 100211-1461 100213-0130 [27040-54020] 121000-0090 121000-0451 [2702016040] 121000-0820 [27020-54190] 121000-1690 121000-1700 121000-2310 Ingram 843522 Toyota 27030-47033 27030-47034 27030-54120 27030-54140 27030-54160 27030-57663 27030-64040 27030-68010 27030-87311 27030-87602-C 27040-54020 dxa4102 65-8402 ANJ278 100210-340 100210-346 100210-368 100210-381 HC Parts IAT A22096 Lester 22096 Lucas (Europe) PIC 290-5301Specifications
Amp | 55 A |
Bottom Mounting Foot Width (B) | 13.5 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10 mm |
Diameter (D.3) | 11 mm |
Grooves | 2 qty |
Groove Width (W.1) | 12 mm |
Length (L.1) | 275 mm |
Mount Inside Length or Pad Mount C-C (C) | 98.5 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 51 mm |
Outside Diameter (O.D.2) | 77 mm |
Plug Code | PL_3601 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 54 mm |
Pulley Type | SOLID |
Unit Type | DENSO |
Vacuum Pump | Yes |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Dyna 100 2.4 D | [2L] | 05.1995-07.2001 |
TOYOTA | Dyna 100 2.4 Diesel | (LH80)[2L] | 01.1984-05.1995 |
TOYOTA | Dyna 150 2.4 D | [2L] | 09.1988-04.1995 |
TOYOTA | Dyna 150 2.8 Diesel | (LY61)[3L] | 08.1985-05.1995 |
TOYOTA | Hiace 2.2 Diesel | (H5G)[L] | 03.1983-11.1989 |
TOYOTA | Hiace 2.2 Diesel | [L] | 03.1983-11.1989 |
TOYOTA | Hiace 2.4 Diesel | [2L] | 05.1984-11.1989 |
TOYOTA | Hiace 2.4 Diesel | (H5G)[2L] | 08.1984-08.1989 |
TOYOTA | Hiace 2.4 Diesel | (LH102)[2L] | 08.1989-08.1995 |
TOYOTA | Hiace 2.4 Diesel 4WD | (H5F)[2L] | 01.1987-01.1988 |
TOYOTA | Hilux 2.4 D | [2L] | 03.1995-08.1997 |
TOYOTA | Hilux 2.4 D | [2L] | 08.1997-04.2005 |
TOYOTA | Hilux 2.4 D | [2L] | 09.1988-08.1997 |
TOYOTA | Hilux 2.4 D | [2L] | 10.1988-07.1997 |
TOYOTA | Hilux 2.4 D | [2L] | 10.1991-07.1997 |
TOYOTA | Hilux 2.4 D 4WD | [2L] | 01.1994-12.1997 |
TOYOTA | Hilux 2.4 D 4WD | [2L] | 09.1988-08.1997 |
TOYOTA | Hilux 2.4 D 4WD | [2L] | 09.1994-07.1997 |
TOYOTA | Hilux 2.4 Diesel | [2L] | 08.1988-07.2005 |
TOYOTA | Hilux 2.4 Diesel 4WD | [2L] | 08.1988-07.2005 |
TOYOTA | Hilux 2.4 TD 4WD | [2L-T] | 08.1988-08.1997 |
TOYOTA | Land Cruiser 2.4 TD | [2L-T] | 10.1985-05.1990 |
VW | Taro 2.4 | [22] | 06.1989-03.1997 |
VW | Taro 2.4 D | [2L] | 06.1989-03.1997 |
VW | Taro 2.4 D | [2L] | 07.1994-03.1997 |
VW | Taro 2.4 D | [2L] | 09.1991-07.1994 |
VW | Taro 2.4 D 4x4 | [2L] | 04.1989-03.1997 |
VW | Taro 2.4 D 4x4 | [2L] | 07.1994-03.1997 |
VW | Taro 2.4 Diesel | [2L] | 07.1994-03.1997 |
VW | Taro 2.4 Diesel 4x4 | [2L] | 07.1994-03.1997 |
Reference Information
10021-03821 LRA1096 SA054250-A 27020-54700 A6139 27030-54263 27020-54383 27030-54262 27020-54354-84 27030-54261 27-1802 20132101BN 27030-54260 27060-54100 27060-54101 445826 111483 J2702054700 2T916 10021-03460 2.70205E+11 ALT421010 10021-03580 10021-03770 10021-03810 ALT30052 40777 AEB0777 210768A 2040101 ALN0777 LRA01096 27020-54250 56424 J2702054352 SA991 ALT916 A12DE0374A2 10021-15900 89212393 27030-54190 437705 2702054250 10021-03400 CGB-13518 ALT1019 12100-05100 ALTS055 27030-54241 002-T916 0986049840 27030-54244 5540301 27030-54243 ALT6467 27030-54242 195.807.055.058 10021-03680 CAL40101AS 10021-03360 195.807.055.395 195.807.055.050 ANM35738 J5112083 2703054190 27030-54252 8EL012429-271 27030-54251 JA777 27030-54250 10021-08160 27020-54353 27020-54354 27020-54351 27020-54352 27030-54253 986049840 10021-03350Video/Publications
002-T916 0986049840 100210-3270 100210-3350 100210-3360 100210-3400 100210-3460 100210-3580 100210-3680 100210-3770 100210-3810 100210-3820 100210-3821 111483 20130103 20130104 27-1802 27020-54250 27020-54351 27020-54352 27020-54353 27020-54354 27020-54383 27030-54190 27030-54241 27030-54242 27030-54243 27030-54244 27030-54250 27030-54260 27030-54261 27030-54262 27030-54263 2T916 40193 40777 A6139 AEB0777 ALN8868 ALT30052 ALT421010 ALT916 ALTS055 CGB-13518 J2702054352 J2702054700 JA777 LRA01096 LRA1096 210768Add Your Number
