Associated Numbers
101211-7370 11.2022 20132742BN 2040247 27060-70500 28-4653 302022RI 9090456 AEK2190 ALT30280 CA2022IR CAL40247AS LRA02190 SA957 UD10061A 23190R
2706070480
1022111500
1022111501
Specifications
Some applications may have wiring plug in different location
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 58 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10 mm |
| Grooves | 4 qty |
| Length (L.1) | 166.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 59 mm |
| Plug Code | PL_3314 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 90 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LEXUS | IS 200 2.0i | [1G-FE] | 01.1999-12.2005 |
| LEXUS | IS 300 3.0 | [2JZ-GE] | 01.2001-12.2005 |
Reference Information
101211-7370 UD10061A 11.2022 9090456 LRA2190 ALT30280 302022RI 2040247 447156 CAL40247AS 27060-70500 ALT6319 115790 23190R LRA02190 AEK2190 CA2022IR 20132742BN ALTF803 SA957 28-4653Video/Publications
101211-7370 11.2022 115790 20132742BN 2040247 23190R 27060-70500 28-4653 302022RI 9090456 AEK2190 ALT30280 ALTF803 CA2022IR CAL40247AS LRA02190 LRA2190 SA957 UD10061AAdd Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
