Brand new OEM DENSO Alternator
PREMIUM LINE
Denso
DENSO
Price:
NZ$ 696.26 including GST
NZ$ 605.44 excluding GST
or four payments of $174.07
with
Learn More
each
A6160(DENSO)
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
DAN1004Associated Numbers
102211-8680 102211-8681 28-6535 301349RI 301349RID 51718502 51859043 63377030 AEK3423 DAN1004 DENDAN1004 LRA03423Specifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 32 mm |
| Diameter (D.1) | 12 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 10 mm |
| Length (L.1) | 196 mm |
| OEM Product | Yes |
| Plug Code | PL_9104 |
| Product Line | Premium Line |
| Product Type | Brand new |
| Pulley Grooves | 4 qty |
| Pulley Outside Diameter (O.D.1) | 54 mm |
| Pulley to Mount Distance (A) | 68 mm |
| Pulley Type | Solid |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| ALFA ROMEO | Mito 1.4 TJet | [198A1.000] | 09.2008-06.2011 |
| ALFA ROMEO | Mito 1.4 TJet | [198A4.000] | 08.2008- |
| ALFA ROMEO | Mito 1.4 TJet | [199A8.000] | 08.2008-06.2011 |
| FIAT | 500 1.2 | [169A4.000] | 07.2007- |
| FIAT | 500 1.4 | [169A3.000] | 10.2007- |
| FIAT | 500 C 1.2 | [169A4.000] | 09.2009- |
| FIAT | 500 C 1.4 | [169A3.000] | 09.2009- |
| FIAT | Doblo 1.4 | [350A1.000] | 10.2005- |
| FIAT | Doblo 1.4 | [843A1.000] | 02.2010- |
| FIAT | Doblo 1.4 | [843A1.000] | 04.2010- |
| FIAT | Linea 1.4 | [350A1.000] | 06.2007- |
| FIAT | Punto 1.2 | [169A4.000] | 03.2012- |
| FIAT | Punto 1.2 | [199B9.000] | 02.2014- |
| FIAT | Punto Evo 1.2 | [169A4.000] | 10.2009-02.2012 |
| FIAT | Punto Evo 1.2 | [199A4.000] | 10.2009-02.2012 |
| FIAT | Punto Evo 1.4 | [199A7.000] | 07.2009-02.2012 |
| FIAT | Punto Evo 1.4 | [350A1.000] | 10.2009-02.2012 |
| FORD | Ka 1.2 | [169A4000] | 10.2008-05.2016 |
| FORD | Ka 1.2 | [FP4] | 10.2008-05.2016 |
Reference Information
| 063377030010 | MAGNETI MARELLI |
| 102211-8680 | DENSO |
| 102211-8681 | DENSO |
| 115647 | CARGO |
| 1705483 | FORD |
| 20098N | WAI / TRANSPO |
| 20104522BN | REAL |
| 20104522OE | REAL |
| 2030225.0 | SANDO |
| 2030225.1 | SANDO |
| 210711 | ERA |
| 28-6535 | ELSTOCK |
| 301349RI | KUHNER |
| 301349RIB | KUHNER |
| 301349RID | KUHNER |
| 4767 | CEVAM |
| 505.569.090.050 | PSH |
| 505.569.090.261 | PSH |
| 51718502 | FIAT |
| 51859043 | FIAT |
| 52003537 | FIAT |
| 56965 | EAI |
| 63377030 | MAGNETI MARELLI |
| 71789568 | FIAT |
| 71794096 | FIAT |
| 89215033 | POWERMAX |
| 8EL011713-481 | HELLA |
| 9S51-10346-GA | FORD |
| AEK3423 | AUTOELECTRO |
| ALE2174 | KRAUF |
| ALT2065 | ROLLCO |
| ALT30573 | WOODAUTO |
| ALT322250 | SIOM |
| ALT6509 | ELECTROLOG |
| ALTL688 | 3EFFE |
| CAL30225AS | CASCO |
| CAL30225GS | CASCO |
| DA2304 | DELCO |
| DAN1004 | DELCO |
| DENDAN1004 | WOODAUTO |
| DRA1194 | DELCO |
| DRA1194X | DELCO |
| F032115647 | CARGO |
| LRA03423 | LUCAS |
| LRA3423 | LUCAS |
| MAN7030 | MAGNETI MARELLI |
| PRAL688 | 3EFFE |
| RAA12205 | DELCO |
| STX100835 | STARDAX |
Video/Publications
A6160(DENSO)View your shopping basket or Browse other items in Alternators.
