Associated Numbers
102211-8280 102211-8281 102211-8310 114462 1535436 1673520 24062N 24062R 28-5674 301886RI 301886RIM 51700670 51700675 51859042 63377011 9213048 9S5110346AA 9S5110346AB AEC1886 ALT12138 CAL30211AS DAN998 LRA03062 UNIT BOM 290-5630Specifications
Amp | 70 A |
Bottom Mounting Foot Width (B) | 32 mm |
Diameter (D.1) | 11 mm |
Diameter (D.2) | 10 mm |
Diameter (D.3) | 10 mm |
Grooves | 4 qty |
Length (L.1) | 196 mm |
OEM Product | Yes |
Outside Diameter (O.D.1) | 55 mm |
Plug Code | PL_9104 |
Product Line | Premium Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 69 mm |
Pulley Type | SOLID |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ALFA ROMEO | MiTo 1.4 | [955A1.000] | 09.2008- |
FIAT | 500 1.2 | [169A4.000] | 10.2007- |
FIAT | 500 1.3 D Multijet | [199B1.000] | 12.2009- |
FIAT | 500 1.4 | [169A3.000] | 10.2007- |
FIAT | 500 C 1.2 | [169A4.000] | 09.2009- |
FIAT | 500 C 1.3 D Multijet | [199B1.000] | 09.2009- |
FIAT | 500 C 1.4 | [169A3.000] | 09.2009- |
FIAT | Panda 1.1 | [187A1.000] | 09.2003- |
FIAT | Panda 1.2 | [188A4.000] | 09.2003- |
FIAT | Panda 1.2 4x4 | [188A4.000] | 10.2004- |
FIAT | Punto Evo 1.4 | [350A1.000] | 10.2009- |
Reference Information
89213048 8EL738211-641 CAL30211GS 1673520 9213048 505.535.070.058 1340 A12DE0405A2 ALT12138 EAA-221857 51700670 2030211 505.535.070.260 52003536 71796293 51700675 CA1886IR 986080560 ANM32353X 63377011 102211-8281 20104112OE LRA3062 102211-8280 51859042 301886RI DRA0133 20104112BN 505.535.070.050 1202463 114462 SB247 AX 1535436 11.1886 95519898 4858 ALT9021 MS1022118280 DAN998 CAL30211AS 95512947 102211-8310 LRA03062 71794211 57405 210405 ALT2065 RNL63377011 301886RIM 9S5110346AB 24062N 9S5110346AA 505.535.070.900 PRAS561 0986080560 CGB-85674 505.535.070.265 24062R ALTS561 2030211.1 63731886010 71784031 1202288 8EL012427-241 NEC1886 MAN7011 AEC1886 63377011010 28-5674Video/Publications
102211-8280 102211-8281 102211-8310 114462 1535436 1673520 24062N 24062R 28-5674 301886RI 301886RIM 51700670 63377011 9213048 9S5110346AA 9S5110346AB AEC1886 ALT12138 AX 1340 CAL30211AS DAN998 LRA03062 LRA3062 UNIT BOM 290-5630 210405Add Your Number
