Associated Numbers
104210-4713 27060-0P183 UD01552ASpecifications
| Amp | 150 A |
| Bottom Mounting Foot Width (B) | 20 mm |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M10x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Grooves | 7 qty |
| Length (L.1) | 166.5 mm |
| Mount Inside Length or Pad Mount C-C (C) | 36 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 52.5 mm |
| Plug Code | PL_4000 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 34 mm |
| Pulley Type | CLUTCH |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Various Models |
Reference Information
UD01552A 27060-0P183 104210-4713Video/Publications
104210-4713 27060-0P183 UD01552AAdd Your Number
