Associated Numbers
04727324AB 13867R 27-5732 421000-0030 4727324AB 554249RI AEK1170 ALT30429 LRA03120 UD01145ASpecifications
Amp | 136 A |
Diameter (D.1) | 9.5 mm |
Diameter (D.2) | 10 mm |
Diameter (D.3) | 9.5 mm |
Grooves | 6 qty |
Length (L.1) | 183.5 mm |
Mount Inside Length or Pad Mount C-C (C) | 85 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 57 mm |
Pad mount thickness (E.1) | 69 mm |
Pad mount thickness (E.2) | 69 mm |
Pad mount thickness (E.3) | 69 mm |
Plug Code | PL_2802 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 21 mm |
Pulley Type | SOLID |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHRYSLER | Voyager 2.4i 16V | [EDO] | 01.2001-12.2007 |
CHRYSLER | Voyager 2.4i 16V | [EDZ] | 01.2001-12.2007 |
DODGE | Caravan 2.4 | [EDZ] | 01.2001-12.2007 |
Reference Information
UD01145A LRA3120 554249RI 447100 AEK1170 27-5732 LRA03120 115936 421000-0030 ALT6737 4727324AB ALT30429 04727324AB 13867RVideo/Publications
04727324AB 115936 13867R 27-5732 421000-0030 554249RI AEK1170 ALT30429 LRA03120 LRA3120 UD01145AAdd Your Number
