Associated Numbers
104210-1530 31100-RX0-A01 A-80583 A6233 AG0623 UD11375A
anj310
ARROWHEAD AND0635, VND0635
DENSO 104210-1530
HONDA 31100RX0A01, 31100-RX0-A01, CSJ53
J&N ELECTRICAL PRODUCTS 400-52444, 400-52444R, 400-52553, 400-52553R
JANNCO 400-52553R
LESTER 11604
1042101530 Honda 31100RX0A01, 31100RX0A01RM, CSJ53 KRAUF ALN6021, ALN6021GB, ALN6021LP, ALN6021ZD WPS 11604N ZAUFER 301N21324Z
dxa4113 65-8598-1
WAI New 11604N
WAI To Be Superseded 11604, 11604R
Acura 31100-RX0-A01, 31100-RX0-A01RM
Alltech 326-11604
Armature G Roy 11604
Atelier Dynamo A11604
Autoelectro AEG1332
Bosch Service Europe 0 986 UR6 082
Denso 104210-1530
EGI A-11604
Elpar Industries 0228036362
Ghibaudi Mario SP AG0623
Honda 31100-RX0-A01, 31100-RX0-A01RM
Lester 11604
Mondial 60-965-280
Part # 11604
Powerite Automotive 11604
Techno CVC IMP-A11604
Wood Auto Supplies ALT30603
Zorko 11604
Specifications
Amp | 120 A |
Diameter (D.1) | 8.5 mm |
Diameter (D.2) | 8 mm |
Diameter (D.3) | 9 mm |
Grooves | 7 qty |
Length (L.1) | 175 mm |
Mount Inside Length or Pad Mount C-C (C) | 46 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 60 mm |
Pad mount thickness (E.1) | 70 mm |
Pad mount thickness (E.2) | 41 mm |
Pad mount thickness (E.3) | 41 mm |
Plug Code | PL_1000 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 41 mm |
Pulley Type | SOLID |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ACURA | ILX 2.4 | 01.2013- | |
HONDA | Civic 2.4 | 01.2012- | |
HONDA | CR-V 2.4 | 01.2012- |
Reference Information
A6233 11604R 104210-1530 31100-RX0-A01 A-80583 AG0623 UD11375A 11604NVideo/Publications
104210-1530 11604R 31100-RX0-A01 A-80583 A6233 AG0623 UD11375AAdd Your Number
