Associated Numbers
104210-6100 104210-6103 11290R 554555RI 7C3T10300EE 7C3TEE 7C3Z10346EA 90-29-5695 A-80391 UD11397ASpecifications
Amp | 200 A |
Diameter (D.1) | 11 mm |
Diameter (D.2) | 11.50 mm |
Diameter (D.3) | 14 mm |
Length (L.1) | 199 mm |
Mount Inside Length or Pad Mount C-C (C) | 73 mm |
OEM Product | No |
Pad mount thickness (E.1) | 55 mm |
Pad mount thickness (E.2) | 55 mm |
Pad mount thickness (E.3) | 55 mm |
Plug Code | PL_3402 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Grooves | 8 qty |
Pulley Outside Diameter (O.D.1) | 71 mm |
Pulley to Mount Distance (A) | 40 mm |
Pulley Type | Solid |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FORD | F Pickups 6.4 V8 | 01.2008-12.2010 |
Reference Information
104210-6100 | DENSO |
104210-6103 | WAI / TRANSPO |
11290R | WAI / TRANSPO |
554555RI | KUHNER |
7C3T10300EE | FORD |
7C3TEE | FORD |
7C3Z10346EA | FORD |
90-29-5695 | WILSON |
A6240 | AS-PL |
A-80391 | DIXIE |
UD11397A | AS-PL |
