Brand new AS-PL Alternator
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 605.94 including GST
NZ$ 526.90 excluding GST
or four payments of $151.49
with
Learn More
each
A6246
No stock in NZ currently
No stock in NZ currently
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Associated Numbers
104210-4220 11179R 12738 15139480 90-29-5617 94745 A-80302 UD11368ASpecifications
| Amp | 135 A |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 11.50 mm |
| Diameter (D.4) | 11.50 mm |
| Length (L.1) | 183.50 mm |
| Mount Inside Length or Pad Mount C-C (C) | 56 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 30 mm |
| Pad mount thickness (E.2) | 30 mm |
| Pad mount thickness (E.3) | 30 mm |
| Pad mount thickness (E.4) | 30 mm |
| Plug Code | PL_2200 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 62 mm |
| Pulley to Mount Distance (A) | 25 mm |
| Pulley Type | Solid |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BUICK | Allure 5.3 V8 | 01.2008-12.2009 | |
| BUICK | Lacrosse 5.3 V8 | 01.2008-12.2009 | |
| CHEVROLET | Impala 5.3 V8 | 01.2006-12.2009 | |
| CHEVROLET | Monte Carlo 5.3 V8 | 01.2006-12.2007 | |
| PONTIAC | Grand Prix 5.3 V8 | 01.2005-12.2008 |
Reference Information
| 104210-4220 | DENSO |
| 11179R | WAI / TRANSPO |
| 12738 | DELCO |
| 15139480 | DELCO |
| 90-29-5617 | WILSON |
| 94745 | DELCO |
| A-80302 | DIXIE |
| UD11368A | AS-PL |
