Associated Numbers
104210-5380 11237R 12798 15846253 210-0680 90-29-5590 A-80359 UD11504ASpecifications
| Amp | 150 A |
| Bottom Mounting Foot Width (B) | 43.3 mm |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | 11 mm |
| Grooves | 6 qty |
| Length (L.1) | 192 mm |
| Mount Inside Length or Pad Mount C-C (C) | 74 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 62 mm |
| Pad mount thickness (E.1) | 43 mm |
| Pad mount thickness (E.2) | 74 mm |
| Pad mount thickness (E.3) | 30 mm |
| Plug Code | PL_2200 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 56 mm |
| Pulley Type | CLUTCH |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHEVROLET | Impala 3.9 | 01.2007-12.2008 | |
| CHEVROLET | Monte Carlo 3.9 | 01.2007- |
Reference Information
15846253 UD11504A 90-29-5590 A-80359 11237R 104210-5380 12798 210-0680Video/Publications
104210-5380 11237R 12798 15846253 210-0680 90-29-5590 A-80359 UD11504AAdd Your Number
