Associated Numbers
104211-3000 104211-3001 104211-3130 195.971.100 20132773OE 2040377 209108 27060-0N090 27060-0N100 28-6673 4272 553910RID AEK3563 ALT30525 CAL40377 CAL40377AS CAL40377ES CAL40377GS CAL40377OS CAL40377RS DAN1094 DENDAN1094 DRA1095 LRA03563 UD11386ASpecifications
| Amp | 100 A |
| Bottom Mounting Foot Width (B) | 20 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M10x1.25 mm |
| Grooves | 6 qty |
| Length (L.1) | 164 mm |
| Mount Inside Length or Pad Mount C-C (C) | 42.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 58 mm |
| Plug Code | PL_1100 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 48 mm |
| Pulley Type | CLUTCH |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Auris 1.4 D-4D | [1ND-TV] | 10.2012- |
| TOYOTA | Corolla 1.4 D-4D | [1ND-TV] | 06.2013- |
Reference Information
104211-3000 20132773OE 4272 104211-3780 104211-3001 27060-0N140 2040377 CAL40377OS LRA03563 UD11386A 209108 27060-0N100 ALT30525 CAL40377ES 195.971.100.260 195.971.100 CAL40377GS LRA04567 195.971.100.261 28-6673 DENDAN1094 20525N 553910RID CAL40377AS ALT6461 DAN1094 28-8676 LRA0004567 27060-0N090 104211-3130 ANM33315X LRA3563 AEK3563 CAL40377RS J5112183 CAL40377 DRA1095 2706033110 195.971.100.050 445858 2040377.1Video/Publications
104211-3000 104211-3001 104211-3130 195.971.100 20132773OE 2040377 209108 27060-0N090 27060-0N100 28-6673 4272 553910RID AEK3563 ALT30525 CAL40377 CAL40377AS CAL40377ES CAL40377GS CAL40377OS CAL40377RS DAN1094 DENDAN1094 DRA1095 J5112183 LRA03563 LRA3563 UD11386AAdd Your Number
