Associated Numbers
0244174B01 101211-7840 102211-0590 102211-0840 12095 13844N 13844R 27060-20110 27060-20140 27060-20200 27060-20200-84 90-29-5363 90-29-5363N 9661219-784 A-8902 ALT30408 UD90128ASpecifications
| Amp | 100 A |
| Bottom Mounting Foot Width (B) | 25 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M10x1.25 mm |
| Grooves | 6 qty |
| Length (L.1) | 168.5 mm |
| Mount Inside Length or Pad Mount C-C (C) | 42 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 65 mm |
| Plug Code | PL_3314 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 44 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LEXUS | RX 300 3.0 V6 | [1MZ-FE] | 01.1999-12.2003 |
| TOYOTA | Highlander 3.0 | [1MZ-FE] | 01.2001-12.2003 |
Reference Information
90-29-5363N 12095 101211-7840 9661219-784 102211-0590 A-8902 102211-0840 ALT30408 27060-20140 0244174B01 27060-20110 27060-20200-84 90-29-5363 13844R UD90128A 13844N 27060-20200Video/Publications
0244174B01 101211-7840 102211-0590 102211-0840 12095 13844N 13844R 27060-20110 27060-20140 27060-20200 27060-20200-84 90-29-5363 90-29-5363N 9661219-784 A-8902 ALT30408 UD90128AAdd Your Number
