Brand new AS-PL Alternator
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 544.79 including GST
NZ$ 473.73 excluding GST
or four payments of $136.20
with
Learn More
each
A6393S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Information
104211-8130Associated Numbers
104211-8130 22032 90-29-5824 A-80613 UD13750ASpecifications
| Amp | 140 A |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | 10.50 mm |
| Diameter (D.3) | 14 mm |
| Length (L.1) | 197 mm |
| Mount Inside Length or Pad Mount C-C (C) | 49 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 50 mm |
| Pad mount thickness (E.2) | 20 mm |
| Pad mount thickness (E.3) | 50 mm |
| Plug Code | PL_2201 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 57 mm |
| Pulley to Mount Distance (A) | 28 mm |
| Pulley Type | Clutch |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHEVROLET | Camaro 3.6 V6 | 01.2012-12.2015 |
Reference Information
| 104211-8130 | DENSO |
| 11787 | WAI / TRANSPO |
| 2013204ABN | REAL |
| 2040A40.0 | SANDO |
| 22032 | DELCO |
| 22859538 | GM |
| 22888109 | GM |
| 90-29-5824 | WILSON |
| A6393S | AS-PL |
| A-80613 | DIXIE |
| ALN5551 | KRAUF |
| CAL40A40AS | CASCO |
| UD13750A | AS-PL |
Video/Publications
A6393SRelated Items
