Associated Numbers
104210-2840 104210-2841 11517R 27060-31180 27060-31260 90-29-5769 J5112150 UD13584ASpecifications
Amp | 100 A |
Bottom Mounting Foot Width (B) | 20 mm |
Diameter (D.1) | 11 mm |
Diameter (D.2) | 11 mm |
Diameter (D.3) | M8x1.25 mm |
Diameter (D.4) | M10x1.25 mm |
Grooves | 7 qty |
Length (L.1) | 166 mm |
Mount Inside Length or Pad Mount C-C (C) | 36 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 52.5 mm |
Plug Code | PL_4000 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 34 mm |
Pulley Type | CLUTCH |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | FJ Cruiser 4.0 | 01.2011- | |
TOYOTA | Tundra 4.0 | 01.2001- |
Reference Information
27060-31180 27060-31260 90-29-5769 2040630 104210-2840 104210-2841 J5112150 104210-2843 A6401S UD13584A CAL40630AS 20132036BN 11517R 104211-8602Video/Publications
104210-2840 104210-2841 11517R 27060-31180 27060-31260 90-29-5769 J5112150 UD13584AAdd Your Number
