Associated Numbers
104210-6000 104210-6001 104210-6110 11181 11181R 15817893 15868747 90-29-5684 A-80201 ALN6000 UD13592ASpecifications
Amp | 220 A |
Bottom Mounting Foot Width (B) | 17.5 mm |
Diameter (D.1) | 10 mm |
Diameter (D.2) | 10 mm |
Diameter (D.3) | 10 mm |
Grooves | 6 qty |
Length (L.1) | 193 mm |
Mount Inside Length or Pad Mount C-C (C) | 35 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 62 mm |
Plug Code | PL_2200 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 24 mm |
Pulley Type | SOLID |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CADILLAC | DTS 4.6 V8 | 01.2006-12.2011 |
Reference Information
15868747 CAL40A02AS 11181 A-80201 2040A02.0 15817893 11181R 104210-6000 104210-6110 2013220ABN ALN6000 UD13592A 104210-6001 90-29-5684Video/Publications
104210-6000 104210-6001 104210-6110 11181 11181R 15817893 15868747 90-29-5684 A-80201 ALN6000 UD13592AAdd Your Number
