Associated Numbers
104210-1000 11047 27060-75460 90-29-5770 ALN6522 UD14160ASpecifications
Amp | 100 A |
Bottom Mounting Foot Width (B) | 20 mm |
Diameter (D.1) | 11 mm |
Diameter (D.2) | 10.5 mm |
Diameter (D.3) | M10x1.25 mm |
Diameter (D.4) | 11 mm |
Grooves | 7 qty |
Length (L.1) | 167 mm |
Mount Inside Length or Pad Mount C-C (C) | 43 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 52.5 mm |
Plug Code | PL_4000 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 38.5 mm |
Pulley Type | CLUTCH |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | 4 Runner 2.7 | ||
TOYOTA | Coaster | ||
TOYOTA | Land Cruiser |
Reference Information
27060-75460 UD14160A 104210-1000 90-29-5770 11047 ALN6522Video/Publications
104210-1000 11047 27060-75460 90-29-5770 ALN6522 UD14160AAdd Your Number
