Associated Numbers
104210-5640 11524R 37300-3C200 90-29-5772 A-80551 ALN5640 UD14165ASpecifications
| Amp | 150 A |
| Bottom Mounting Foot Width (B) | 20 mm |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M10x1.25 mm |
| Diameter (D.4) | M10x1.25 mm |
| Grooves | 6 qty |
| Length (L.1) | 174 mm |
| Mount Inside Length or Pad Mount C-C (C) | 43.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 53 mm |
| Plug Code | PL_4001 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 44 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HYUNDAI | Centennial 3.8 | 01.2008- | |
| HYUNDAI | Equus 3.8 | 01.2008- | |
| HYUNDAI | Genesis 3.8 | 01.2008- | |
| KIA | Quoris 3.8 | 01.2008- |
Reference Information
37300-3C200 11524R 104210-5640 A-80551 ALN5640 90-29-5772 UD14165AVideo/Publications
104210-5640 11524R 37300-3C200 90-29-5772 A-80551 ALN5640 UD14165AAdd Your Number
