Associated Numbers
104210-2930 11622 290-10511 90-29-5797 A-80529 ALN7611 BC3T-10300-CA BC3Z-10346-B BC3Z-10346-C UD14254ASpecifications
| Amp | 150 A |
| Bottom Mounting Foot Width (B) | 15 mm |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | M10x1.5 mm |
| Grooves | 8 qty |
| Length (L.1) | 164.5 mm |
| Mount Inside Length or Pad Mount C-C (C) | 58 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 69 mm |
| Plug Code | PL_3402 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 43 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | F 250 Super Duty 6.7 | 01.2011-12.2014 | |
| FORD | F 350 Super Duty 6.7 | 01.2011-12.2014 | |
| FORD | F 450 Super Duty 6.7 | 01.2011-12.2014 | |
| FORD | F 550 Super Duty 6.7 | 01.2011-12.2014 |
Reference Information
90-29-5797 A-80529 ALN7611 BC3Z-10346-C BC3Z-10346-B 290-10511 104210-2930 BC3T-10300-CA 11622 UD14254AVideo/Publications
104210-2930 11622 290-10511 90-29-5797 A-80529 ALN7611 BC3T-10300-CA BC3Z-10346-B BC3Z-10346-C UD14254AAdd Your Number
