Information
104210-2930Associated Numbers
104210-2930 11622 290-10511 90-29-5797 A-80529 ALN7611 BC3T-10300-CA BC3Z-10346-B BC3Z-10346-C UD14254ASpecifications
Amp | 150 A |
Bottom Mounting Foot Width (B) | 15 mm |
Diameter (D.1) | 10 mm |
Diameter (D.2) | 10 mm |
Diameter (D.3) | M10x1.5 mm |
Length (L.1) | 164.50 mm |
Mount Inside Length or Pad Mount C-C (C) | 58 mm |
OEM Product | No |
Plug Code | PL_3402 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Grooves | 8 qty |
Pulley Outside Diameter (O.D.1) | 69 mm |
Pulley to Mount Distance (A) | 43 mm |
Pulley Type | Solid |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FORD | F 250 Super Duty 6.7 | 01.2011-12.2014 | |
FORD | F 350 Super Duty 6.7 | 01.2011-12.2014 | |
FORD | F 450 Super Duty 6.7 | 01.2011-12.2014 | |
FORD | F 550 Super Duty 6.7 | 01.2011-12.2014 |
Reference Information
104210-2930 | DENSO |
11622 | WAI / TRANSPO |
290-10511 | ROBERT'S |
90-29-5797 | WILSON |
A-80529 | DIXIE |
ALN7611 | KRAUF |
BC3T-10300-CA | FORD |
BC3Z-10346-B | FORD |
BC3Z-10346-C | FORD |
UD14254A | AS-PL |
Video/Publications
