Associated Numbers
UD14670A UD20710A 27060-31110 CAL40326AS 1042104570 1042104571 1042104572 1042104573 1042105010 57557 28-6971 ALN0106 LRA03861 195.965.130 2040326.0 270600P150 270600P151 2706031110 2706031111 2706031140 2706031141 11137 11137N 90-29-5619N 90-29-5619 ALT30490Specifications
Amp | 130 A |
Bottom Mounting Foot Width (B) | 18 mm |
Diameter (D.1) | 11 mm |
Diameter (D.2) | 11 mm |
Diameter (D.3) | M8x1.25 mm |
Diameter (D.4) | M10x1.25 mm |
Grooves | 7 qty |
Length (L.1) | 167 mm |
Mount Inside Length or Pad Mount C-C (C) | 32.5 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 52.5 mm |
Plug Code | PL_4000 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 38.5 mm |
Pulley Type | CLUTCH |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
LEXUS | ES 350 3.5 V6 | 01.2007- | |
LEXUS | RX 350 3.5 V6 | 01.2007- | |
TOYOTA | Avalon 3.5 V6 | 01.2005- | |
TOYOTA | Highlander 3.5 V6 | 01.2008- | |
TOYOTA | Venza 3.5 V6 | 01.2009- |
Reference Information
270600P150 1042105010 UD20710A 2706031141 104210-2100 2706031140 LRA03861 27060-31111 27060-31110 90-29-5619 ALN0106 270600P151 ALTF860 90-29-5619N 104210-5010 195.965.130 11137N 28-6971 27060-0P151 27060-0P150 1042104570 1042104571 27060-31140 ALT30490 LRA3861 A6465S 27060-31141 1042104572 1042104573 2706031111 2040326 2706031110 57557 104210-4570 ALTJ037 104210-4572 104210-4571 104210-4573 CAL40326AS UD14670A 11137 ALT6176Video/Publications
1042104570 1042104571 1042104572 1042104573 1042105010 11137 11137N 195.965.130 2040326.0 27060-31110 270600P150 270600P151 2706031110 2706031111 2706031140 2706031141 28-6971 57557 90-29-5619 90-29-5619N ALN0106 ALT30490 ALTF860 ALTJ037 CAL40326AS LRA03861 LRA3861 UD14670A UD20710AAdd Your Number
