Brand new AS-PL Alternator
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 475.47 including GST
NZ$ 413.45 excluding GST
or four payments of $118.87
with
Learn More
each
A6499S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Information
104211-8160Associated Numbers
104211-8160 104211-8161 20016 22865612 22988006 90-29-5823 A-80612 UD15013A UNIT BOM 290-5681Specifications
| Amp | 150 A |
| Bottom Mounting Foot Width (B) | 25 mm |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 12 mm |
| Diameter (D.3) | 12 mm |
| Length (L.1) | 194 mm |
| Mount Inside Length or Pad Mount C-C (C) | 60 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 25 mm |
| Pad mount thickness (E.2) | 50 mm |
| Pad mount thickness (E.3) | 50 mm |
| Plug Code | PL_2201 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 57.50 mm |
| Pulley to Mount Distance (A) | 32 mm |
| Pulley Type | Clutch |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CADILLAC | SRX 3.6 | 01.2012-12.2016 | |
| CHEVROLET | Colorado 3.6 | 01.2013-12.2014 | |
| CHEVROLET | Equinox 2.4 | 01.2013-12.2016 | |
| CHEVROLET | Equinox 3.6 | 01.2013-12.2014 | |
| GMC | Terrain 3.6 | 01.2013-12.2016 |
Reference Information
| 104211-8160 | DENSO |
| 104211-8161 | DENSO |
| 20016 | DELCO |
| 22865612 | OPEL |
| 22988006 | OPEL |
| 90-29-5823 | WILSON |
| A-80612 | DIXIE |
| UD15013A | AS-PL |
| UNIT BOM 290-5681 | WAI / TRANSPO |
Video/Publications
A6499SRelated Items
