Information
104210-2000Associated Numbers
104210-2000 104210-2001 11508R 20821397 23480514 90-29-5765 A-80539 A6511S ALN2109 DA2374 DRA1264 UD15186A
10396863 104210-5390 11369R 12846 90-29-5713 A-80197 UD11374A
0986UR6058 Bosch ruil
10396863 Opel
1042105390 Denso show
195949130 PSH
2706050390 Toyota
ALT30655 Wood Auto
WOOALT30655 Wood Auto
104210-5391 84009359
0986UR6058 Bosch ruil
10396863 Opel
1042105390 Denso show
195949130 PSH
2706050390 Toyota
ALT30655 Wood Auto
WOOALT30655 Wood Auto
Ace Electric CA11369N
Bosch Reman AL8836X
Bosch Service Europe 0-986-UR6-058
DENSO 104210-539, 104210-5390
DENSO Auto Parts 210-0641
General Motors 10396863, 84009359
IAT A11369
Lester 11369
NAPA 213-9756
PIC 290-5231
Road Force RF499011843
65-8798
ARROWHEAD AND0487, VND0487
BOSCH AL8836X
DENSO 104210-5390
GENERAL MOTORS 10396863
J&N ELECTRICAL PRODUCTS 400-52467, 400-52467R, 400-52468, 400-52468R
JANNCO 400-52468R
LESTER 11369
Specifications
| Amp | 140 A |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | 10 mm |
| Diameter (D.3) | 14 mm |
| Length (L.1) | 191 mm |
| Mount Inside Length or Pad Mount C-C (C) | 49 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 50 mm |
| Pad mount thickness (E.2) | 20 mm |
| Pad mount thickness (E.3) | 50 mm |
| Plug Code | PL_2200 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 62 mm |
| Pulley to Mount Distance (A) | 29 mm |
| Pulley Type | Clutch |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CADILLAC | CTS 3.6 | [LLT] | 09.2011- |
| CADILLAC | CTS 3.6 AWD | [LLT] | 01.2010- |
| CADILLAC | CTS 3.6 AWD | [LLT] | 09.2011- |
Reference Information
| 104210-2000 | DENSO |
| 104210-2001 | DENSO |
| 11508R | WAI / TRANSPO |
| 20821397 | CADILLAC |
| 23480514 | CADILLAC |
| 90-29-5765 | WILSON |
| A6511S | AS-PL |
| A-80539 | DIXIE |
| ALN2109 | KRAUF |
| DA2374 | DELCO |
| DRA1264 | DELCO |
| UD15186A | AS-PL |
