Brand new AS-PL Alternator
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 514.79 including GST
NZ$ 447.64 excluding GST
or four payments of $128.70
with
Learn More
each
A6512S
3
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Information
102211-0512Associated Numbers
102211-0512 102211-0513 11092R 28-5654 553299RI 553299RIR 57532 89215469 90-29-5652 A6512S ALN1012 DA1327 DRA0217 LRA03042 UD15183A XR83-10300-CC XR83-10300-CDSpecifications
| Amp | 120 A |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 12 mm |
| Diameter (D.3) | 12 mm |
| Length (L.1) | 183 mm |
| Mount Inside Length or Pad Mount C-C (C) | 74 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 73 mm |
| Pad mount thickness (E.2) | 73 mm |
| Pad mount thickness (E.3) | 73 mm |
| Plug Code | PL_4000 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 58.50 mm |
| Pulley to Mount Distance (A) | 42 mm |
| Pulley Type | Clutch |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| JAGUAR | S-Type 3.0 V6 | [AJ-V6] | 01.1999-10.2007 |
| JAGUAR | S-Type 3.0 V6 | [FB] | 01.1999-10.2007 |
Reference Information
| 101211-7890 | DENSO |
| 102211-0512 | DENSO |
| 102211-0513 | DENSO |
| 11092R | WAI / TRANSPO |
| 20132732BN | REAL |
| 20132732RC | REAL |
| 2040237.0 | SANDO |
| 2040237.2 | SANDO |
| 28-5654 | ELSTOCK |
| 553299RI | KUHNER |
| 553299RIR | KUHNER |
| 57532 | EAI |
| 89215469 | POWERMAX |
| 90-29-5652 | WILSON |
| A6512S | AS-PL |
| ALN1012 | KRAUF |
| ANM32437X | ANDEL |
| CAL40237AS | CASCO |
| CAL40237RS | CASCO |
| DA1327 | DELCO |
| DRA0217 | DELCO |
| LRA03042 | LUCAS |
| LRA3042 | LUCAS |
| UD15183A | AS-PL |
| XR8310300BA | JAGUAR |
| XR8310300BC | FORD |
| XR8310300BD32 | JAGUAR |
| XR83-10300-CC | JAGUAR |
| XR83-10300-CD | JAGUAR |
| XR842452 | JAGUAR |
| XR88577 | JAGUAR |
Video/Publications
A6512SRelated Items
