Brand new AS-PL Alternator
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 550.34 including GST
NZ$ 478.56 excluding GST
or four payments of $137.59
with
Learn More
each
A6534S
1
Associated Numbers
063377419010 104210-3840 115579 1496230 2040231 210402 27-6566 4109 4M5T-10300-AA 4M5T-10300-AB 4M5T-10300-CA 4M5T-10300-CB 4M5T-10300-CC 553273RID 595.578.120.050 595.578.120.260 63377422 89215042 9090438 ALT30175 CAL40231 CAL40231AS CAL40231ES CAL40231GS CAL40231OS CAL40231RS DRA0088 LRA03456 UD15373ASpecifications
| Amp | 120 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8 mm |
| Diameter (D.2) | 8 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Length (L.1) | 167 mm |
| Mount Inside Length or Pad Mount C-C (C) | 52 mm |
| OEM Product | No |
| Plug Code | PL_3402 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 54 mm |
| Pulley to Mount Distance (A) | 41 mm |
| Pulley Type | Clutch |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | C-Max 1.8 TDCi | [KKDA] | 01.2005-12.2007 |
| FORD | C-Max 1.8 TDCi | [KKDA] | 01.2007-12.2010 |
| FORD | Focus 1.8 TDCi | [KKDA] | 01.2005- |
| FORD | Focus 1.8 TDCi | [KKDB] | 01.2005- |
Reference Information
| 063377419010 | MAGNETI MARELLI |
| 104210-3840 | DENSO |
| 115579 | CARGO |
| 1496230 | FORD |
| 2040231 | SANDO |
| 210401 | ERA |
| 210402 | ERA |
| 210404 | ERA |
| 27-6566 | ELSTOCK |
| 32118930 | HERTH+BUSS |
| 4109 | CEVAM |
| 446932 | LOGISTIK |
| 4M5T-10300-AA | FORD |
| 4M5T-10300-AB | FORD |
| 4M5T-10300-CA | FORD |
| 4M5T-10300-CB | FORD |
| 4M5T-10300-CC | FORD |
| 553273RID | KUHNER |
| 595.578.120.050 | PSH |
| 595.578.120.260 | PSH |
| 63377422 | MAGNETI MARELLI |
| 89215042 | POWERMAX |
| 9090438 | FRIESEN |
| A134.528 | PSH |
| A146.740 | PSH |
| ALT30175 | WOODAUTO |
| ALT6520 | ELECTROLOG |
| ALTF035 | 3EFFE |
| ANM32308X | ANDEL |
| CAL40231 | CASCO |
| CAL40231AS | CASCO |
| CAL40231ES | CASCO |
| CAL40231GS | CASCO |
| CAL40231OS | CASCO |
| CAL40231RS | CASCO |
| DRA0088 | DELCO |
| F032115579 | CARGO |
| LRA03456 | LUCAS |
| LRA3456 | LUCAS |
| UD15373A | AS-PL |
Video/Publications
