Associated Numbers
104210-6340 104211-0070 23006 23050 90-29-5805 A-80508 AL7782X BL3T-10300-BC BL3T10300BC BL3Z-10346-A BL3Z10346A FL3T-10300-DA FL3Z-10346-D UD15408ASpecifications
| Amp | 225 A |
| Bottom Mounting Foot Width (B) | 15 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 11 mm |
| Diameter (D.3) | M10x1.5 mm |
| Grooves | 6 qty |
| Length (L.1) | 163 mm |
| Mount Inside Length or Pad Mount C-C (C) | 57 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 57 mm |
| Plug Code | PL_3402 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 44.5 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | F-Series 3.5 V6 | 01.2011- | |
| FORD | F-Series 3.7 V6 | 01.2011- |
Reference Information
104211-0070 BL3T-10300-BC 90-29-5805 23006 BL3T10300BC 104210-6340 23050 A-80508 FL3Z-10346-D UD15408A AL7782X BL3Z-10346-A BL3Z10346A FL3T-10300-DA 0AL7782XVideo/Publications
104210-6340 104211-0070 23006 23050 90-29-5805 A-80508 AL7782X BL3T-10300-BC BL3T10300BC BL3Z-10346-A BL3Z10346A FL3T-10300-DA FL3Z-10346-D UD15408AAdd Your Number
