Associated Numbers
104210-6860 22048 90-29-5894 A-80690 ALN6861 UD15411A
ARROWHEAD 400-52490R
DENSO 104210-6860
GENERAL MOTORS 23487089
LESTER 14020
Armature G Roy 14020
Denso 104210-6860
EGI A-14020
GM 22949466
Lester 14020
Part # 14020
Powerite Automotive 14020
Techno CVC IMP-A14020
104211-1200, TN104211-1200
GM 84143539
Lester 44006
Specifications
| Amp | 240 A |
| Bottom Mounting Foot Width (B) | 50.5 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | 12.5 mm |
| Grooves | 6 qty |
| Length (L.1) | 164 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 60 mm |
| Plug Code | PL_2200 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 73 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHEVROLET | Silverado 2500 6.0 | ||
| CHEVROLET | Silverado 3500 6.0 | ||
| GMC | Sierra 2500 6.0 | ||
| GMC | Sierra 3500 6.0 |
Reference Information
A-80690 104210-6860 ALN6861 22048 90-29-5894 UD15411AVideo/Publications
104210-6860 22048 90-29-5894 A-80690 ALN6861 UD15411AAdd Your Number
