Associated Numbers
104211-3650 UD20714A ALN3114 270600V200 270600V210Specifications
| Amp | 100 A |
| Bottom Mounting Foot Width (B) | 16 mm |
| Diameter (D.1) | M10x1.25 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | M10x1.25 mm |
| Grooves | 6 qty |
| Length (L.1) | 165 mm |
| Mount Inside Length or Pad Mount C-C (C) | 63.5 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 55 mm |
| Plug Code | PL_2306 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 26 mm |
| Pulley Type | CLUTCH |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Camry 2.0 | [6ARFSE] | 01.2015-12.2016 |
Reference Information
104211-3650 UD20714A ALN3114 270600V200 270600V210Video/Publications
104211-3650 270600V200 270600V210 ALN3114 UD20714AAdd Your Number
