Associated Numbers
421000-7181 UD20713A A-80835Specifications
| Amp | 180 A |
| Diameter (D.1) | 8.5 mm |
| Diameter (D.2) | 9.5 mm |
| Diameter (D.3) | 11.5 mm |
| Grooves | 6 qty |
| Length (L.1) | 202 mm |
| Mount Inside Length or Pad Mount C-C (C) | 51 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 52.5 mm |
| Pad mount thickness (E.1) | 73 mm |
| Plug Code | PL_2804 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 50 mm |
| Pulley Type | CLUTCH |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHRYSLER | Pacyfica 3.6 V6 | 01.2017- | |
| CHRYSLER | Pacyfica 3.6 V6 | 01.2018- | |
| CHRYSLER | Pacyfica 3.6 V6 | 01.2019- | |
| CHRYSLER | Pacyfica 3.6 V6 | 01.2020- | |
| CHRYSLER | Voyager 3.6 V6 | 01.2020- |
Reference Information
421000-7181 UD20713A A-80835 A6602SVideo/Publications
421000-7181 A-80835 A6602S UD20713AAdd Your Number
