Brand new AS-PL Alternator
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 380.59 including GST
NZ$ 330.95 excluding GST
or four payments of $95.15
with
Learn More
each
A6606S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Associated Numbers
101211-0550 28-3766 31400-77E24 JA1293IR UD16876A 111779 CAL35278GS DA2384 DRA1274 101211-0551 102211-5070 102211-5150 102211-5151 102211-5520 104210-8121 J5118018 944390457910 MRA45791 A005TA4291 A005TA4291ZC A5TA4291 A5TA4291AC A5TA4291ZC 185.509.070 20137872OE 2035278.1 31400-59J00 31400-65D00 31400-65D01 31400-77E020 31400-77E021 31400-77E22 31400-77E23 13680N 13680R ALT30124Specifications
| Amp | 70 A |
| Bottom Mounting Foot Width (B) | 58.50 mm |
| Diameter (D.1) | 10.50 mm |
| Diameter (D.2) | M8x1.25 mm |
| Length (L.1) | 153 mm |
| OEM Product | No |
| Plug Code | PL_3302 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 5 qty |
| Pulley Outside Diameter (O.D.1) | 55 mm |
| Pulley to Mount Distance (A) | 91 mm |
| Pulley Type | Solid |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SUZUKI | Baleno 1.8 GTX | [J18A] | 03.1996-05.2002 |
| SUZUKI | Baleno 1.8 i 16V | [J18A] | 08.1996-05.2002 |
| SUZUKI | Grand Vitara 2.0 4x4 | [J20A] | 03.1998-07.2003 |
Reference Information
| 101211-0550 | DENSO |
| 101211-0551 | DENSO |
| 102211-5070 | DENSO |
| 102211-5150 | DENSO |
| 102211-5151 | DENSO |
| 102211-5520 | DENSO |
| 104210-8121 | DENSO |
| 13680N | WAI / TRANSPO |
| 13680R | WAI / TRANSPO |
| 185.509.070 | PSH |
| 185.509.070.415 | PSH |
| 185.509.070.460 | PSH |
| 20137872OE | REAL |
| 2035278.1 | SANDO |
| 209353 | ERA |
| 210888 | ERA |
| 28-3766 | ELSTOCK |
| 31400-59J00 | SUZUKI |
| 31400-65D00 | SUZUKI |
| 31400-65D01 | SUZUKI |
| 31400-77E020 | SUZUKI |
| 31400-77E021 | SUZUKI |
| 31400-77E22 | SUZUKI |
| 31400-77E23 | SUZUKI |
| 31400-77E24 | SUZUKI |
| 3140077E24000 | SUZUKI |
| 3140077E25000 | SUZUKI |
| 944390457910 | MAGNETI MARELLI |
| A005TA4291 | MITSUBISHI |
| A005TA4291ZC | MITSUBISHI |
| A130.989 | PSH |
| A149.371 | PSH |
| A5TA4291 | MITSUBISHI |
| A5TA4291AC | MITSUBISHI |
| A5TA4291BC | MITSUBISHI |
| A5TA4291ZC | MITSUBISHI |
| A6606S | AS-PL |
| ALT30124 | WOODAUTO |
| ALT538 | ROLLCO |
| ALT6272 | ELECTROLOG |
| ALTS040 | 3EFFE |
| ANM33494X | ANDEL |
| CAL35278GS | CASCO |
| DA2384 | DELCO |
| DRA1274 | DELCO |
| J5118018 | HERTH+BUSS |
| JA1293IR | HC PARTS |
| MRA45791 | MAGNETI MARELLI |
| RNL0550ND | RNL |
| RNL0720ND | RNL |
| STX100076 | STARDAX |
| STX100076R | STARDAX |
| STX100189 | STARDAX |
| STX100189R | STARDAX |
| STX102037 | STARDAX |
| STX102037R | STARDAX |
| UD16876A | AS-PL |
Video/Publications
A6606SRelated Items
