Brand new AS-PL Alternator
STANDARD LINE
AS-PL
MAGNETON
Price:
NZ$ 398.71 including GST
NZ$ 346.70 excluding GST
or four payments of $99.68
with
Learn More
each
A9034
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
4.43114E+11Associated Numbers
047903015M 0986049390 11.1626 11.1626M 112387 20108101OE 20110511 2048101 21610R 28-2898 301626RI 441040032266 443113516590 443113516591 56578 8EL012428-241 8EL737896-001 9090120 9213321 9516590 9516591 A9034 AEA5211 ALT20404 CA1626IR CAL48101GS DRA4153 EAA-221190 LRB00511 SA342Specifications
| Amp | 90 A |
| Bottom Mounting Foot Width (B) | 16 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | M8x1.25 mm |
| Diameter (D.3) | 8.50 mm |
| Diameter (D.4) | 8.50 mm |
| Length (L.1) | 179 mm |
| Mount Inside Length or Pad Mount C-C (C) | 66.50 mm |
| OEM Product | No |
| Plug Code | PL_9105 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 50 mm |
| Pulley to Mount Distance (A) | 33 mm |
| Pulley Type | Solid |
| Unit Type | MAGNETON |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| SKODA | Felicia 1.3 | [135B] | 10.1994-12.1998 |
| SKODA | Felicia 1.3 | [135L] | 10.1994-03.1998 |
| SKODA | Felicia 1.3 | [136B] | 10.1994-12.1998 |
| SKODA | Felicia 1.3 | [AMG] | 03.1998-03.2001 |
| SKODA | Felicia 1.3 | [AMG] | 08.1996-12.1998 |
| SKODA | Felicia 1.3 | [AMH] | 08.1996-06.2001 |
| SKODA | Felicia 1.3 | [AMJ] | 10.1994-03.1998 |
| SKODA | Felicia 1.3 Fun | [135B] | 06.1997-03.2001 |
| SKODA | Felicia 1.3 Fun | [135M] | 06.1997-03.2001 |
| SKODA | Felicia 1.3 Fun | [136B] | 06.1997-03.2001 |
| SKODA | Felicia 1.3 Fun | [136M] | 06.1997-03.2001 |
| SKODA | Felicia 1.3 LX | [135B] | 11.1994-12.1998 |
| SKODA | Felicia 1.3 LX | [AMG] | 08.1996-12.1998 |
| SKODA | Felicia 1.3 LXi | [136B] | 11.1994-12.1998 |
| SKODA | Felicia 1.3 LXi | [AMH] | 08.1996-12.1998 |
Reference Information
| 047903015M | VW |
| 0986049390 | BOSCH |
| 112387 | CARGO |
| 20108101OE | REAL |
| 2048101.1 | SANDO |
| 210488 | ERA |
| 21610R | WAI / TRANSPO |
| 28-2898 | ELSTOCK |
| 301626RI | KUHNER |
| 32049390 | HERTH+BUSS |
| 441040032266 | MAGNETON |
| 443113516590 | MAGNETON |
| 443113516591 | MAGNETON |
| 445.005.090.110 | PSH |
| 445.005.090.340 | PSH |
| 445.005.090.350 | PSH |
| 445.005.090.770 | PSH |
| 4G0803R | RIDEX |
| 516591 | VALEO |
| 56578 | EAI |
| 89213321 | POWERMAX |
| 8EL012428-241 | HELLA |
| 8EL737896-001 | HELLA |
| 943316261010 | MAGNETI MARELLI |
| 944390901200 | MAGNETI MARELLI |
| A9034 | AS-PL |
| AEA5211 | AUTOELECTRO |
| ALG1626 | KRAUF |
| ALT3520 | SIOM |
| ALTS188 | 3EFFE |
| ALTX027 | ELECTROLOG |
| ANM36373X | ANDEL |
| CA1626IR | HC PARTS |
| CAL48101GS | CASCO |
| DA5263 | DELCO |
| DRA4153 | DELCO |
| F032112387 | CARGO |
| LRB00511 | LUCAS |
| LRB511 | LUCAS |
| MARC1626 | MAGNETI MARELLI |
| MGN9516591 | WOODAUTO |
| MRA90120 | MAGNETI MARELLI |
| PRAS188 | 3EFFE |
| STA0256R | BOVEZ |
| STX100462 | STARDAX |
Video/Publications
