Brand new AS-PL Alternator
STANDARD LINE
AS-PL
UNIVERSAL
Price:
NZ$ 252.45 including GST
NZ$ 219.52 excluding GST
or four payments of $63.11
with
Learn More
each
A9078
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
R2223701000Associated Numbers
R222-3701000 UD10970ASpecifications
| Amp | 55 A |
| Bottom Mounting Foot Width (B) | 19 mm |
| Diameter (D.1) | M10x1.25 mm |
| Diameter (D.2) | 12 mm |
| Diameter (D.3) | 12 mm |
| Length (L.1) | 184 mm |
| Mount Inside Length or Pad Mount C-C (C) | 62 mm |
| OEM Product | No |
| Plug Code | PL_9115 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 1 qty |
| Pulley Groove Width (W.1) | 10.50 mm |
| Pulley Outside Diameter (O.D.1) | 55.00 mm |
| Pulley Outside Diameter (O.D.2) | 80.00 mm |
| Pulley to Mount Distance (A) | 42 mm |
| Pulley Type | Solid |
| Unit Type | UNIVERSAL |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| UAZ | 2104 | ||
| UAZ | 2105 | ||
| UAZ | 2107 |
Reference Information
| R222-3701000 | RUSSIA |
| UD10970A | AS-PL |
Video/Publications
