Associated Numbers
0986UR6247 11148 2614548 37300-2C120 90-22-5695 A-9587 A-9608 UD12126ASpecifications
Amp | 100 A |
Bottom Mounting Foot Width (B) | 20 mm |
Diameter (D.1) | 10.5 mm |
Diameter (D.2) | 10.5 mm |
Diameter (D.3) | M10x1.25 mm |
Diameter (D.4) | M10x1.25 mm |
Grooves | 6 qty |
Length (L.1) | 177 mm |
Mount Inside Length or Pad Mount C-C (C) | 56.5 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 55 mm |
Plug Code | PL_3304 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 43.5 mm |
Pulley Type | SOLID |
Unit Type | HYUNDAI / KIA |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | Genesis Coupe 2.0 | 01.2010-12.2012 |
Reference Information
90-22-5695 37300-2C120 2614548 11148 UD12126A 00986UR6247 A-9608 0986UR6247Video/Publications
0986UR6247 11148 2614548 37300-2C120 90-22-5695 A-9587 A-9608 UD12126AAdd Your Number
